Phase Structure of (La_,Mg_,Nd)₅Ni₁₉ Hydrogen Storage Alloy

Abstract:

The crystal structure of (La,Mg,Nd)₅Ni₁₉ alloy has been investigated using powder x-ray diffraction. A Rietveld refinement is used to determine the phase structures for tying to find out the correlations of lattices among the phases in this hydrogen storage alloy. The results show that the alloy consists of three phases, which correspond to (La,Mg)₃Nd₂Ni₁₉ with a Pr₅Co₁₉-type structure, La (Mg,Nd)Ni₇ phase with a Ce₂Ni₇-type structure and (La,Mg)₃Nd₂Ni₁₉ with a Ce₅Co₁₉-type structure. Mg and Nd substitute for La atom at the 4f position for Pr₅Co₁₉-type and Ce₂Ni₇-type structures and the 6c position for Ce₅Co₁₉-type structure, respectively. It induces a good lattice match along the a-axisand b-axis among the three phases. The three kinds of structures might form a rod-like shape structural unit by stacking along the c-axis. This phase constitution seems to be beneficial for the cyclic stability of the hydrogen storage alloys.

• Periodical: Applied Mechanics and Materials (Volume 455)
• Pages: 66-70
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.455.66
• Online since: November 2013
• Authors: Qiang He, Yong Quan Guo, Zhen Zhen Zheng
• Keywords: (La,Mg,Nd)₅Ni₁₉ Hydrogen Storage Alloy, Phase Structure, Rietveld Analysis

References

[1] K. Kadir, T. Sakai and I. Uehara. Structural investigation and hydrogen storage capacity of LaMg2Ni9 and (La0. 65Ca0. 35)(Mg1. 32Ca0. 68)Ni9 of the AB2C9type structure. J. Alloys Compd. Vol. 302 (2000), p.112.

DOI: 10.1016/s0925-8388(00)00581-8

[2] T. Kohno et al. Hydrogen storage properties of new ternary system alloys: La2MgNi9, La5Mg2Ni23, La3MgNi14. J. Alloys Compd. Vol. 311 (2000), p. L5.

DOI: 10.1016/s0925-8388(00)01119-1

[3] Hiroshi Hayakawa et al. Crystal Structures of La–Mg–Nix (x=3–4) System Hydrogen Storage Alloys. Mater. Trans. Vol. 46(6) (2005), p.1393.

[4] E. Akiba, H. Hayakawa and T. Kohno. Crystal structures of novel La-Mg-Ni hydrogen absorbing alloys. J. Alloys Compd. Vol. 408–412 (2006), p.280.

DOI: 10.1016/j.jallcom.2005.04.180

[5] T. Ozaki et al. Stacking structures and electrode performances of rare earth-Mg-Ni-based alloys for advanced nickel-metal hydride battery. J. Alloys Compd. Vol. 446–447 (2007), p.620.

DOI: 10.1016/j.jallcom.2007.03.059

[6] Shigekazu Yasuoka et al. Development of high-capacity nickel-metal hydride batteries using superlattice hydrogen-absorbing alloys. J. Power Sources. Vol. 156 (2006), p.662.

DOI: 10.1016/j.jpowsour.2005.05.054

[7] J. Gao et al. Effect of annealed treatment on microstructure and cyclic stability for La-Mg-Ni hydrogen storage alloys. J. Power Sources. Vol. 209 (2012), p.257.

DOI: 10.1016/j.jpowsour.2012.02.088

[8] A.Q. Deng et al. Phase Structure and Electrochemical Properties of Hydrogen Storage Alloys La4-xPrxMgNi19(x=0-2. 0). Rare Metal Mat Eng. Vol. 37(6) (2008), p.1037.

[9] Amélie Férey et al. Elaboration and characterization of magnesium-substituted La5Ni19 hydride forming alloys as active materials for negative electrode in Ni-MH battery. Electrochim. Acta. Vol. 54 (2009), p.1710.

DOI: 10.1016/j.electacta.2008.09.069

[10] Z.Y. Liu et al. Cyclic stability and high rate discharge performance of (La, Mg)5Ni19 multiphase alloy. Int. J. Hydrogen energy. Vol. 36 (2011), p.4370.

DOI: 10.1016/j.ijhydene.2010.12.134

[11] X.Q. Shen et al. The structure and 233K electrochemical properties of La0. 8-xNdxMg0. 2Ni3. 1Co0. 25Al0. 15 (x=0. 0–0. 4) hydrogen storage alloys. Int. J. Hydrogen energy. Vol. 34 (2009), p.2661.

[12] Y. Li et al. The effect of Nd content on the electrochemical properties of low-Co La–Mg–Ni-based hydrogen storage alloys. J. Alloys Compd. Vol. 458 (2008), p.357.

DOI: 10.1016/j.jallcom.2007.03.106

[13] Y. Li et al. Effect of rare earth elements on electrochemical properties of La-Mg-Ni-based hydrogen storage alloys. Int. J. Hydrogen energy. Vol. 34(2009), p.1399.

DOI: 10.1016/j.ijhydene.2008.11.049

[14] R.A. Young, in: Introduction to the rietveld method In, The Rietveld Method, edtied by R.A. Young, Oxford: IUCr, Oxford University Press(1995).

[15] R.J. Hill, C.J. Howard. J. Appl. Cryst. Vol. 20(1987), p.467.
