Analysis and Simulation of Mineral Grading Sieve Mechanism Motion Based on ADAMS

Abstract:

This paper introduces a kind of screening machinery that applied to mineral grading.It needs to simplify its structure for expedient simulation and build the three-dimensional solid model of the screen frame in the SolidEdge circumstance, and then be imported into ADAMS software to improve and perfect the model and conduct the analysis and simulation. Ultimately the curves of motion and changes of pressure angle were obtained. The approximate formula of the screen frames acceleration can be obtained to find out the inertial acceleration of the mineral particles by analyzing and simulating its kinematics, which supplys the basis of Stress analysis of mineral particles on the sifter. It provides a theory to optimize screening machinery by analyzing the changes of pressure angle.

• Periodical: Applied Mechanics and Materials (Volumes 457-458)
• Pages: 1554-1557
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.457-458.1554
• Online since: October 2013
• Authors: Xian Cheng, Wei Min Dong
• Keywords: Adam, Kinematics Analysis, Kinematics Simulation, Screen Frame

References

[1] X.X. Duan: Crushing and Grinding (Metallurgical Industry Press, China 2006).

[2] W, D, Guo: Virtual Prototype Technology and ADAMS Application Tutorial Examples (Beihang University Press, China2008).

[3] L, P, Chen: Dynamic Analysis of Mechanical System and ADAMS Application Tutorial(Tsinghua University press, China2005).

[4] J. Xie X.Q. Zhang C.J. Wang Tea Screening Test Based on Three Translational Parallel Mechanism, Vol. 43(2012), No. 10, pp.101-104(in Chinese).
