Model and Fabrication of Biomimetic Integrated Porous Core Laminated Composite

Abstract:

This paper deals with imitating a novel type of biomimetic integrated composite with porous core layer from the beetle elytra microstructures. Firstly,the microstructures of the elytron of Anoplophora Glabripennis, Anomala Corpulenta Motschulsky, Prosopocoilus Inclinatus and Melolonthidae were examined with SEM. Inspired by these structure characteristics, a biomimetic composite model was proposed, in which the two face layers were interconnected with a porous core layer, and there are continuous fibers embedded into these three layers to enhance mechanical performance of the laminated composite. Then a specimen of this laminated composite with porous core layer was made. The procedures include: weaving a piece of two layers space fabric by glass fibers as the preform of the composite,filling the mixed resin which contained 50% granular paraffin wax and 50% epoxy resin into the space of the fabric, putting it into a flat mold, keeping 36 hours, and finally heating the composite to remove the paraffin wax to form the porous core layer. The experiment showed that the model of integrated porous core laminated composite inspired by the beetle elytra structure is reasonable and this novel type of lightweight composite material was manufacturable.

• Periodical: Applied Mechanics and Materials (Volume 461)
• Pages: 397-401
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.461.397
• Online since: November 2013
• Authors: Jian Mei Fan
• Keywords: Beetle Elytron, Biomimetic, Laminated Composite, Porous Core Layer

References

[1] H.M. Burte, D.R. Van, P. M. Hemenger, The potential impact of biotechnology on composites, J. Technomic Publishing Company, Inc. (1986) 65-68.

[2] A.C. Neville, B.M. Luke, A two system for chitin-protein complexes in insect cuticle, J. Tissue Cell. 1(1969)689-707.

DOI: 10.1016/s0040-8166(69)80041-8

[3] K.M. Rudall, W. Kenchington, The chitin system,J. Biology Review. 48(1973)597-636.

[4] G. Steve, S. Rebecca, The insect exoskeleton: a natural structural composite,J. JOM. 11, 41(1989) 60-63.

[5] Schiavone, Gunderson S. The components and structure of insect exoskeleton compared to man-made advanced composites,C. Proc. Amer. Soc. Comp, 1989, pp.876-885.

[6] H.B. Hepburn, A. Ball. On the structure and mechanical properties of beetle shells,J. Material Science. 8(1973)618-623.

[7] C.T. Xiang J.H. Fan, On the Strengthening and Toughening Mechanism of Natural Composites and Research of Biomimetic Composites,J. Advances In Mechanics. 24(1990)220-231.

[8] B. Chen , X.H. Peng, Research on the microstructure of insect cuticle and the strength of a biomimetic preformed hole composite,J. Micro. 33(2002)571-574.

DOI: 10.1016/s0968-4328(02)00014-8

[9] Chen B, X.H. Peng, Microstructure of Natural Biocomposites and Reseach of Biomimetic Composites,J. ACTA MATERIAE COMPOSITAE SINICA. 3, 17(2000)59-62.

[10] J.X. CHEN, Q.Q. NI , Distribution of trabeculae and elytral surface structures of the horned beetle, allomyrina dichotoma (linne)(coleopteran: scarabaeidae),J. Entomologia sinica. 1, 19(2002)55-61.

DOI: 10.1111/j.1744-7917.2002.tb00143.x

[11] J.X. CHEN, Q.Q. NI, Fine structure of trabeculae in the elytra of allomyrina dichotoma (linne) and prosopocoilus inclinatus (motschulsky)(coleopteran: scarabaeidae)J. Entomologia sinica. 2, 18(2001)115-123.

DOI: 10.1111/j.1744-7917.2001.tb00477.x

[12] Yu Q.Q., W.Y. Wang, Z.X. Yang, Microstructure and Mechnics Research of Cybister Elytra,J. Progress in Natural Science. 16(2006)340-365.

[13] Q.Q. NI, J.X. CHEN, Interlaminar reinforcement mechanism in a beetle fore-wing,J. JSME International Journal, Series C. 4, 44(2001)260-262.
