Bionic Sawblade Based on Grasshopper Incisor for Corn Stalk Cutting

Abstract:

Grasshopper [Chondracris rosea rosea (De Geer)] possesses sharp and serrated incisors that have an advantageous capacity for cutting plant. The special outline of the incisor lobe described by reverse engineering was used for the prototype of the teeth of bionic saw manufactured by Wire Electronic Discharge Machine. In total one traditional saw and four bionic saws (which teeth are full teeth, first teeth, second teeth, and third teeth) were manufactured and compared for the cutting property. The experiments for cutting corn stalk using bionic saws and traditional saw were conducted in laboratory conditions using universal testing machine at quasi-static speed of 4 mm per second. The results show that the cutting force and the average energy consumed for cutting corn stalk using bionic saw is lower compared with commercial saw. 8.95 J consumed for cutting a corn stalk using bionic saw of full teeth in average is lower by 12.85% than 10.27 J needed for traditional saw. In additional the average cutting force for four types of bionic saws is lower than that of traditional saw. The least average force is 41.11 N for bionic saw of first teeth much lower than 71.97 N for traditional saw. In conclusion, the special shaped incisors of grasshopper are a potential prototype that can be exploited to develop new cutting element to cut lignocellulosic biomass more efficiently. These results would be helpful for designing cutting elements on crop harvesting, biomass size reduction and other processing machinery.

• Periodical: Applied Mechanics and Materials (Volume 461)
• Pages: 491-498
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.461.491
• Online since: November 2013
• Authors: Chang Ying Li, Hong Lei Jia, Zhi Hong Zhang, Gang Wang
• Keywords: Bionic Saw, Corn Stalk, Grasshopper, Incisors

References

[1] M. F. Demirbas, M. Balat, H. Balat, Potential contribution of biomass to the sustainable energy development, Energy Conversion and Management. 50 (2009) 1746-1760.

DOI: 10.1016/j.enconman.2009.03.013

[2] O. Ioannidou, A. Zabaniotou, E. Antonakou, K. Papazisi, A. Lappas, C. Athanassiou, Investigating the potential for energy, fuel, materials and chemicals production from corn residues (cobs and stalks) by non-catalytic and catalytic pyrolysis in two reactor configurations, Renewable and sustainable energy reviews. 13 (2009).

DOI: 10.1016/j.rser.2008.01.004

[3] L. Junfeng, Y. -h. Wan, J. M. Ohi, Renewable energy development in China: Resource assessment, technology status, and greenhouse gas mitigation potential, Applied energy. 56 (1997) 381-394.

DOI: 10.1016/s0306-2619(97)00018-4

[4] H. Chen, R. Hou, Y. Gong, H. Li, M. Fan, Y. Kuzyakov, Effects of 11 years of conservation tillage on soil organic matter fractions in wheat monoculture in Loess Plateau of China, Soil and Tillage Research. 106 (2009) 85-94.

DOI: 10.1016/j.still.2009.09.009

[5] T. Dyson, World food trends and prospects to 2025, Proceedings of the National Academy of Sciences. 96 (1999) 5929-5936.

DOI: 10.1073/pnas.96.11.5929

[6] C. Igathinathane, A. Womac, S. Sokhansanj, Corn stalk orientation effect on mechanical cutting, Biosystems engineering. 107 (2010) 97-106.

DOI: 10.1016/j.biosystemseng.2010.07.005

[7] T. Abbasi, S. Abbasi, Is the Use of Renewable Energy Sources an Answer to the Problems of Global Warming and Pollution?, Critical Reviews in Environmental Science and Technology. 42 (2012) 99-154.

DOI: 10.1080/10643389.2010.498754

[8] C. Igathinathane, L. Pordesimo, M. Schilling, E. Columbus, Fast and simple measurement of cutting energy requirement of plant stalk and prediction model development, Industrial Crops and Products. 33 (2011) 518-523.

DOI: 10.1016/j.indcrop.2010.10.015

[9] C. Igathinathane, A. Womac, S. Sokhansanj, S. Narayan, Size reduction of high-and low-moisture corn stalks by linear knife grid system, biomass and bioenergy. 33 (2009) 547-557.

DOI: 10.1016/j.biombioe.2008.09.004

[10] Information on http: /en. wikipedia. org/wiki/Grasshopper.

[11] H. Kocabıyık, R. Polat, A. Oktem, Determination of cutting properties, protein and mineral content of silage corn stalk, Asian Journal of Chemistry. 21 (2009) 5580-5590.

[12] K. G. Satyanarayana, G. G. Arizaga, F. Wypych, Biodegradable composites based on lignocellulosic fibers—an overview, Progress in Polymer Science. 34 (2009) 982-1021.

DOI: 10.1016/j.progpolymsci.2008.12.002

[13] M. O'Dogherty, J. Huber, J. Dyson, C. Marshall, A study of the physical and mechanical properties of wheat straw, Journal of Agricultural Engineering Research. 62 (1995) 133-142.

DOI: 10.1006/jaer.1995.1072

[14] M. Yu, A. Womac, C. Igathinathane, P. Ayers, M. Buschermohle, Switchgrass ultimate stresses at typical biomass conditions available for processing, biomass and bioenergy. 30 (2006) 214-219.

DOI: 10.1016/j.biombioe.2005.10.005

[15] M. Nazari Galedar, A. Jafari, S. Mohtasebi, A. Tabatabaeefar, A. Sharifi, M. O'Dogherty, et al., Effects of moisture content and level in the crop on the engineering properties of alfalfa stems, Biosystems engineering. 101 (2008) 199-208.

DOI: 10.1016/j.biosystemseng.2008.07.006

[16] K. J. Shinners, Engineering principles of silage harvesting equipment, Silage Science and Technology. (2003) 361-403.

DOI: 10.2134/agronmonogr42.c8
