Power Supply Design of Magnetic Resonance Sounding Equipment for Detecting Mine Groundwater

Abstract:

On the basis of the principles and characteristics of the various switching power supply, we have designed a high-power supply which can be used for the magnetic resonance sounding equipment for detecting mine ground water. The characteristics of the switching power supply are the full-bridge converter as the main power topology and the SG3525 chip as the core of the control. The high frequency PWM signal generated by the SG3525 can drive the four power switch tubes of the full-bridge circuit to conduct alternately thought the IR2110, so we can get continuous and stable DC output voltage. The design of the switching power supply has a lot of advantages, such as high efficiency, low noise, high stability, and small volume weight.

• Periodical: Applied Mechanics and Materials (Volume 461)
• Pages: 519-523
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.461.519
• Online since: November 2013
• Authors: Chen Sun, Jun Lin
• Keywords: Groundwater Advanced Detection, MRS, SG3525, Switching Power Supply
