Design of a Digital Positioning System with Sinusoidal Change of the Jerk

Abstract:

In this paper we consider design of a digital electromechanical positioning system that ensures controlled change of the jerk. A system that is formed from a load and an actuating device is used as an object. For the proposed sinusoidal change of the jerk, the appropriate changes of the acceleration, velocity and displacement were found.. The control algorithm which ensures the motion of the object with sinusoidal change of the jerk so that the requirements which are related to the maximum values of the acceleration, velocity and displacement are satisfied, is also proposed. The digital feedforward and feedback controllers that are realized this algorithm are designed. Furthermore the simulation of that system is performed, which is confirmed the proposed theory.

• Periodical: Applied Mechanics and Materials (Volume 474)
• Pages: 255-260
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.474.255
• Online since: January 2014
• Authors: Mihaylo Y. Stoychitch
• Keywords: Controlled Jerk, Digital Controller, Feedback, Feedforward Controller, Positioning System, Trajectory Planning

References

[1] Anton Cervin, Johan Eker, Bo Bernhardss-on, Karl-Eric A, Feedback Feedforward Scheduling of Control Tasks, Real Time Systems (Special Issure on Control Theoretical Approaches to Real Time Computing), To appear in (2002).

DOI: 10.1109/emrts.2003.1212734

[2] Paul Lumbrechts, Trajectory planning and feedforward design for electromechanical motion systems, Report nr. DCT 2003-08, University of Technology Eindhoven.

[3] Paul Lambrechts, Matthijs Boerlage, Maarten Steinbuch, Trajectory planning and feedforward design for electromechanical motion systems, Control Engineering Practice 13 (2005) 145-157, ScienceDirect.

DOI: 10.1016/j.conengprac.2004.02.010

[4] Vito Cerone, Mario Milanese, Diego Regruto, Robust feedforward design for a two-degrees of freedom controller , System & Control Letters, Volume 56, Issues 11-12, Dec. 2007, pp.736-741.

DOI: 10.1016/j.sysconle.2007.04.010

[5] H. Z. Li, Z. M. Gong, W. Lin, and T. Lippa, Motion profile planning for reduced jerk and vibration residuals, SIMTech techni-cal reports, Volume 8, No 1, 2007, pp.32-37.

[6] Kim Doang Nguyen, Teck-Chew Ng and I-Ming Chen, On Algorithms for Planning S-curve Motion Profiles, International Journal of Advanced Robotic Systems, Vol. 5, No 1 (2008), ISSN 1729-8806, pp.99-106.

DOI: 10.1109/aim.2007.4412440

[7] G.M. Clayton, , S. Tien, A.J. Fleming, S.O.R. Moheimani, S. Devasia, Inverse feedforward of charge controlled piezoposi-tioners, Mechatronics 18 (2008) 273–281 , ScienceDirect.

DOI: 10.1016/j.mechatronics.2007.07.006

[8] Mihaylo Y. Stoychitch (in Serbian Михајло Ј. Стојчић), Design of Linear Control Systems (in Serbian), University of B. Luka, Faculty of Mechanical Engineering, (2009).

[9] Mihajlo J. Stojčić, Bojan Knežević, The controller design for tracking trajectory with controlled jerk, DEMI 2011 Proceedings, Banja Luka, (2011), pp.905-911.

[10] Mihajlo J. Stojčić, Bojan Knežević, Design of digital controller that ensures robust tracking trajectory with controlled jerk, (In Serbian), JUPITER 37 Proceedings, Belgrade 2011, pp.4-4. 16.

[11] Mihaylo Y. Stoychitch, Design of an Electromechanical Positioning System with Sinusoidal Change of the Jerk, Proc. of the Intl. Conf. on Future Trends in Structural, Civil, Environmental and Mechanical Engineering - FTSCEM 2013, doi: 10. 3850/ 978-981-07-7021-1_48, pp.35-38.
