Trailing Edge Deformation Mechanism for Active Variable - Camber Wind Turbine Blade

Abstract:

Blade root fatigue stress, primarily resulting from wind shear and turbulence, is a critical factor in wind turbine design. Blade mounted aerodynamic control devices have been shown to have the potential to reduce this. However, limited research exists into suitable devices, with great challenges being involved in meeting the requirements for use on large turbines. The blade designed in this work addresses this by employing a piezoceramic actuated compliant mechanism, contained within a flexible matrix composite structure. The resulting mechanism design achieves a sectional change in lift coefficient of ΔC_L +0.4 to 0.15. The performance of the blade is analysed with a quasi-steady time marching BEM model, employing optimal control. A reduction of 21.59% in the standard deviation of the flap-wise bending moment was achieved, a comparable result to previous load control investigations.

• Periodical: Applied Mechanics and Materials (Volume 493)
• Pages: 444-449
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.493.444
• Online since: January 2014
• Authors: Bu Yung Kosasih, Michael Dicker
• Keywords: Airfoil, Compliant Mechanism, Load Control, Variable-Camber, Wind Turbine (WT)

References

[1] G.A.M. Barlas, A. van Kuik, Aeroelastic modeling and comparison of advanced active flap control concepts for load reduction on the upwind 5 MW wind turbine, in: The proceedings of the European Wind Energy conference & exhibition, Marseille, (2009).

DOI: 10.1002/we.1560

[2] P.S. Veers, T.D. Ashwill, H.J. Sutherland, D.L. Laird, D.W. Lobitz, D.A. Griffin, J.F. Mandell, W.D. Musial, K. Jackson, M. Zuteck, A. Miravete, S.W. Tsai, J.L. Richmond, Trends in the design, manufacture and evaluation of wind turbine blades, Wind Energy 6 (2003).

DOI: 10.1002/we.90

[3] W. Musial, G. Scott, J. Jonkman, S. Butterfield, Definition of a 5 MW reference wind turbine for offshore system development, Technical report NREL/TP-500-38060 (2009).

DOI: 10.2172/947422

[4] M. Lackner, T. Barlas, Smart rotor blade technology applied to the upwind reference turbine, in: The proceedings of the IEA topical expert meeting on the application of smart structures for large turbine blades, Sandia National Labs, Alberquerque, USA, (2008).

[5] M.A. Lackner, G.A.M. van Kuik, The performance of wind turbine smart rotor control approaches during extreme loads, Journal of Solar Energy Engineering, Trans. ASME, 132 (2010) 0110081 – 0110088.

DOI: 10.1115/1.4000352

[6] B.A.H. Marrant, T.H. van Holten, Comparison of smart rotor blade concepts for large offshore wind turbines, Offshore Wind Energy and other Renewable Energies in Mediterranean and European Seas, Civitavecchia, (2006).

[7] M. Drela, XFOIL: An analysis and design system for low Reynolds number airfoils, Conference on low Reynolds number airfoil aerodynamics, University of Notredame, (1989).

DOI: 10.1007/978-3-642-84010-4_1

[8] S. Kota, J. Hetrick, R. Osborn, D. Paul, E. Pendleton, P. Flick, C. Tilmann, Design and application of compliant mechanisms for morphing aircraft structures, Smart Structures and Materials 2003: Industrial and Commercial Applications of Smart Structures Technologies, San Diego, (2003).

DOI: 10.1117/12.483869

[9] F. Gandhi, M. Frecker, A. Nissly, Design optimization of a controllable camber rotor airfoil, AIAA Journal, 46 (2008) 142-153.

DOI: 10.2514/1.24476

[10] BS EN 6100-1-2005 Wind Turbines – part 1: Design Requirements, (2005).

[11] P.S. Veers, Three-dimensional wind simulation, Sandia Report, SAND88 – 0152 UC-261, (1988).

[12] M. Selig, Z. Du, A 3-D stall delay model for horizontal axis wind turbine performance prediction, AIAA, AA-98-0021.

DOI: 10.2514/6.1998-21
