Research and Application of BPJV-1200/6K High Voltage Frequency Converter in Belt Conveyor

Abstract:

In this paper, the BPJA-1200/6K mine-used high-voltage frequency converter designed and developed with Power Flex7000 is introduced. How to replace the fluid coupling used in original belt conveyor system with the converter to achieve the purpose of speed regulation by frequency variation as well as long distance driving are discussed. At the same time, the composition of the centralized control system for the belt conveyor is discussed and the speed regulation strategy and the main control functions are introduced. The converser system has been applied to a mine belt conveyor and the running results are better.

• Periodical: Applied Mechanics and Materials (Volumes 494-495)
• Pages: 1548-1551
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.494-495.1548
• Online since: February 2014
• Authors: Wen Tao Lu*, Yu Qing Li
• Keywords: Belt Conveyor, Coal Mine, Frequency Converter, Speed Regulation

References

[1] Zhang Chun, Shen Yimin, Zhang Chunxian. Research and Application of BPJV-1400/3. 3 Flame-Proof and Intrinsically Safe High Voltage Inverter. Colliery Mechanical & Electrical Technology. 2013 (2). 83-84.

[2] Wu Fang. Design and Application of Large Power High Voltage Converter[D]. Shandong University. (2012).

[3] Zhu Longji, Zhang Xuli. Key Technologies of Explosion-proof Frequency Converter Applied in Coal Mine，Industry and Mine Automation. 2012, 38(2).

[4] Chen Lei. Application research for low voltage Explosion-proof Frequency Converter. Science & Technology Information，2009, (6). p.70.

[5] Xiao Zheng, Lin Tao. Frequency Control System Design and implementation Based on Fuzzy Control of the Belt. Electric Drive. 2008, 38(9). 66-67.
