Research of the Key Technologies for Explosion-Proof and Intrinsically Safe High Voltage Frequency Converter

Abstract:

Some key technical problems encountered in making mine-used explosion-proof and intrinsically safe high-voltage frequency converter are researched and discussed. The inverter integrates common-mode voltage rejection of DC reactor, deionized water circulation cooling technology, selective harmonic elimination technology, explosion-proof technology, adopts advanced Power Flex7000 with good speed regulation performance. The circulation water cooling device presented in this paper has high cooling efficiency, small size, lower operating noise and good water-saving effect. This inverter has actually run in Huainan coal mine and the application effect was better.

• Periodical: Applied Mechanics and Materials (Volumes 494-495)
• Pages: 1552-1555
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.494-495.1552
• Online since: February 2014
• Authors: Wen Tao Lu*, Yu Qing Li
• Keywords: Coal Mine, Explosion-Proof, Frequency Converter, High Voltage

References

[1] Zhu Longji, Zhang Xuli. Key Technologies of Explosion-proof Frequency Converter Applied in Coal Mine，Industry and Mine Automation2012, 38(2).

[2] Chen Lei. Application research for low voltage Explosion-proof Frequency Converter. Science & Technology Information，p.70, 2009, (6).

[3] Bao jianyu. Research on topology and control strategy for current source type multi-voltage inverter. [D]; Zhejiang University; (2007).

[4] Zhang Chun, Shen Yimin, Zhang Chunxian. Research and Application of BPJV-1400/3. 3 Flame-Proof and Intrinsically Safe High Voltage Inverter. Colliery Mechanical & Electrical Technology. 2013 (2). 83-84.

[5] Wang haibin, Lou Guohuan, zhang Wenxin. Research and application of the method of harmonic elimination for the inverter. Data Technology and Appliction. 2011. 6.
