A Chaotic Carrier Frequency SVPWM Strategy to Reduce the Harmonic Distortion

Abstract:

Harmonics always have a negative impact on control precision and grid quality. It has been found out that harmonic distribution is very germane to carrier frequency. Based on the analysis of conventional SVPWM, in this paper a chaotic carrier frequency SVPWM strategy is proposed, where the theory of chaos is applied to generate the desired random source for SVPWM carrier frequency. Simulation result proves that chaotic carrier frequency SVPWM can not only improve the waveform quality, reduce the low-order harmonics, and also flatten the high-order harmonics effectively.

• Periodical: Applied Mechanics and Materials (Volumes 494-495)
• Pages: 1577-1581
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.494-495.1577
• Online since: February 2014
• Authors: Shi Sheng Zheng*, Yong Jun Zhang, Yong Kang Zhang
• Keywords: Chaos Theory, Harmonics Suppression, SVPWM, THD

References

[1] Q. R. Zeng, L. C. Chang, An Advanced SVPWM-Based Predictive Current Controller for Three-Phase Inverters in Distributed Generation Systems. IEEE Trans. Ind. Electron, vol. 55, no. 3, pp.1235-1246, Mar. (2008).

DOI: 10.1109/tie.2007.907674

[2] M. C. Li, G. H. Liu, Z. L. Liao, Study on Harmonics and Influence on the Electro – Magnetic Torque of SVPWM[J]. Small & Special Electrical Machines, 2004(7) 16-19.

[3] X. W. Kang, K. X. Yu, Z. H. Liu, Simulation and Harmonic Analysis of SVPWM [J]. Electric Drive Automation, 2005 27 (1) 11-13.

[4] Y. Gao, J. H. Xie, Hao Chen, Modulation and Harmonic Analysis of SVPWM [J]. Small & Special Electrical Machines, 2006 (7) 10-12.

[5] A. M. Trzynadlowski, S. Legowski, and R. L. Kirlin, Random Pulse Width Modulation Technique for Voltage-Controlled Power Inverters in Conf. Rec. 1987 IEEE-/AS Annu. Mtg., pp.863-868.

DOI: 10.1080/00207219008921243

[6] Y. P. Zhao, G. J. Tan, X. Zhang, P. F. Guo and L. Zhang, Supression of Electromagnetic Interference in PWM Voltage Source Rectifier Based on Chaotic SVPWM, Power Engineering and Automation Conference (PEAM), September 2011, Vol. 2, Page(s): 99 – 102.

DOI: 10.1109/peam.2011.6134917

[7] H. Li., F. Lin, Z. Li SM IEEE, W. A. Halang, and Bo Zhang, Chaotic SVPWM Control and its Application in EMI suppression for PV Inverters, Antennas and Propagation in Wireless Communications (APWC), 2012 IEEE – APS Topical Conference on Digital Object Identifier, 2012, Page(s) : 1213-1216.

DOI: 10.1109/apwc.2012.6324964

[8] Y. P. Zhao, G. J. Tan, X. Zhang, P. F. Guo and L. Zhang, Improvement on Electromagnetic Compatibility of Voltage Source PWM Rectifier Based On Chaotic SVPWM, Mechanic Automation and Control Engineering (MACE), 2011 Second International Conference on Digital Object Identifier, 2011, Page(s) : 4115 – 4118.

DOI: 10.1109/mace.2011.5987908

[9] Y. M. Lu, X. F. Huang, B. Zhang, Z. Y. Mao, Two Chaos-Based PWM Strategy for Suppression of Harmonics, The Sixth World Congress on Intelligent Control and Automation, Vol. 1, 2006, Page(s): 953 – 957.

DOI: 10.1109/wcica.2006.1712485

[10] G. L. Lin, X. Y. Chen, F. C. Liu, Analysis of Power Spectral Density of the Output Voltage in Chaotic PWM Inverter [J]. Proceedings of the CSEE, 2006, 26 (20) : 79-83.
