Numerical Simulation Analysis of Electronic Equipment Thermal Reliability in Steady-State Temperature Field

Abstract:

In recent years, with the rapid development of electronic information technology, electronic devices are used in all areas of our lives. The power consumption is transmitted to the surrounding through the form of heat when electronic components at work. Each of the components is a source of heat when it is working. If it works in a hot environment long times, the stability will be affected and its life will also decreases. Therefore, in the initial design phase of electronic equipment, thermal stability and thermal reliability must be analyzed to reduce these uncertainties. This article solve the optimal layout problem of components in PCB board by establish micro unit heat balance method. It also concludes that the micro unit heat balance method is reasonable through ANSYS finite element analysis.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 3184-3187
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.3184
• Online since: February 2014
• Authors: Wei Ming Li*
• Keywords: ANSYS, Electronic Devices, Heat Balance, Numerical Simulation

References

[1] Qin Li, Haidong Liu, Minbo Zhu. The application of thermal simulation in electronic equipment design [J]. Electronics Process Technology, 2010, 27 (3): 165 -181.

[2] Yuanbo Zhang. The thermal analysis and optimization design of air-cooled CPU heat sink [D]. Wuhan: Huazhong University of Science and Technology, 2010, 15-34.

[3] Meng Wang. The thermal design and structure optimization of high density and enclosed electronic equipment [D]. Xi'an: Xi'an University of Electronic Science and Technology, 2011, 56-60.

[4] Jianfeng Ren. The key technologies in the study of electronic Equipment structural dynamic response [D]. Xi'an: Xi'an University of Electronic Science and Technology, 2011, 6-12.

[5] Fei Tang, Hongfei Teng An Improved Genetic Algorithm and Its Application to Layout Optimization [J]. Journal of Software , 2011, 10 (10): 1096-1102.

[6] Jiyuan Zhu, Dejian Zhou, Zhaohua Wu. The study of board-level circuit Vibration Analysis and components layout optimization technology [J]. Electronic Mechanical Engineering, 2010, 23 (1): 14-10.

[7] Guang Wen, Fan Wu. The study of PCB component layout optimization based on APDL [J]. Electronics Process Technology, 2011, 30 (3): 151-153.
