Numerical Simulation and Experimental Study of Inner Flow Field in Marine Centrifugal Pump

Abstract:

It was simulated the flow fields of the CLH-type marine centrifugal pump based on average N-S equations and standard k-ε turbulent model, using the ANSYS CFX12.1 code. With the calculation results, the velocity distribution of the flow field in the centrifugal pump is analyzed under different working conditions. The analogue results, which indicate the relationship between the total head, efficiency, shaft power and flow rate, are compared with performance experimental ones, and it shows that the simulation data coincides with experimental ones in allowable acceptance, which meet the requirements of practical application. Furthermore, in order to analyze the inner flow field distribution in the centrifugal pump in detail, and validate the simulation results, the inner flow field is tested by particle image velocimetry (PIV) measurement.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 4593-4596
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.4593
• Online since: February 2014
• Authors: Xin Xiang Chen*, Guo You Wang, Kai Wang, Ming Gao Tan, Liang Dong
• Keywords: CFX, Marine Centrifugal Pump, Numerical Simulation, PIV

References

[1] Dai Cui, Dong Liang, Liu Houlin, et al. Unsteady constant value calculation and particle image velocimetry experiment in full passages of centrifugal pump impeller Transactions of the Chinese Society of Agricultural Engineering [J], 2013, 29(2): 66-73.

[2] Westra R W, Broersma L, Andel K V, et al. PIV measurements and CFD computations of secondary flow in a centrifugal pump impeller. ASME Journal of Fluids Engineering [J], 2010, 132(6): 611-617.

DOI: 10.1115/1.4001803

[3] Li Guowei, Wang Yan, Lv Xiuli, et al. Numerical simulation of three-dimensional flow field in centrifugal pump with deviated short splitter vanes. Transactions of the Chinese Society of Agricultural Engineering [J], 2011, 27(7): 151-155.

[4] Wang Yang, Dai Cui. Analysis on pressure fluctuation of unsteady flow in a centrifugal pump. Transactions of the Chinese Society for Agricultural Machinery [J], 2010, 41(3): 91-95.

[5] Liu Houlin, Wang Yong, Yuan Shouqi, et al. Effects of impeller outlet width on the vibration and noise from centrifugal pumps induced by folw. Journal of Huazhong University of Science and Technology: Natural Science Edition [J], 2012, 40(1): 123-127.

DOI: 10.3850/978-981-07-2826-7_126

[6] Dong Liang, Liu Houlin, Tan Minggao, et al. Numerical calculation of whole and non-whole flow field in centrifugal pumps. Journal of Drainage and Irigation Machinery Engineering [J], 2012, 30(3): 274-278.

[7] Kergourlay G, Younsi M, Bakir F, et al．Influence of Splitter Blades on the Flow Field of a Centrifugal Pump: Test-Analysis Comparison. International Journal of Rotating Machinery [J], 2007, 19(5): 35-40.

DOI: 10.1155/2007/85024
