Vibration Control of an Engine Mount for UAV Activated by Piezostack Actuator

Abstract:

In this paper, vibration control performance of piezostack active engine mount system for unmanned aero vehicle (UAV) is evaluated via computer simulation. As a first step, the dynamic model of engine mount system which is supported at three points is derived. In the configuration of engine mount system, the inertia type of piezostack based active mount is installed for active vibration control. Then, the vibration level of UAV engine is measured. To attenuate the vibration which is transmitted from engine, a sliding mode controller which is robust to uncertain parameters is designed. Vibration control performances of active engine mount system are evaluated at each mount and center of gravity. Effective Control results are presented in both time and frequency domains.

You might also be interested in these eBooks

Advances in Mechanical Engineering (ICME)

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 52-54)

Pages:

358-364

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.52-54.358

Citation:

Cite this paper

Online since:

March 2011

Authors:

Jong Seok Oh, Seung Bok Choi

Keywords:

Active Vibration Control, Engine Mount, Piezostack Actuator, Sliding Mode Controller, Unmanned Aerial Vehicle (UAV)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Kim, J. W., The Requirements of Payload for the UAV, Current Industrial and Technological Trends in Aerospace, Vol. 6, No. 2, pp.245-249 (2007).

Google Scholar

[2] Yu, Y., Naganathan, N. G. and Dukkipati, R. V., A Literature Review of Automotive Vehicle Engine Mounting systems , Mechanism and Machine Theory, Vol. 36, No. 1, p.123~142 (2001).

DOI: 10.1016/s0094-114x(00)00023-9

Google Scholar

[3] Oh, J. S., Choi, S. B., Cho, H. J., Lee, C.H., and Cho, M. W., Performance Evaluation on an Active Camera Mount system for UAV via Hardware-in-the-loop-simulation, Transaction of the Korea Society for Noise and Vibration Engineering, vol. 20, no. 8, p.767~773 (2010).

DOI: 10.5050/ksnve.2010.20.8.767

Google Scholar

[4] Park, D. H., and Choi, S. B., Active Vibration Control of UAV EO/IR Sensor Mount Using Piezoelectric Actuator", Transaction of the Korea Society for Noise and Vibration Engineering, vol. 18, no. 12, p.1278~128 (2008).

DOI: 10.5050/ksnvn.2008.18.12.1278

Google Scholar

[5] Edward, C. and Spurgeon, S. K., Sliding Mode Control, Taylor & Francis, London, UK, Chapter 3, 4 (1998).

Google Scholar

[6] Utkin, V., Guldner, J and Shi, J., Sliding Mode Control in Electromechanical Systems, Taylor & Francis, London, UK, Chapter 6 (1999).

Google Scholar
