New Methodology of Monitoring for the Contamination Degree of Insulators

Abstract:

Insulator is an essential part of overhead line. In recent years, the news about the insulator flashover is increasing. The main reason of insulator flashover is insulator surface contamination. Insulator flashover is a serious threat to the safe and stable of transmission lines operation. With the development of China's comprehensive national strength, power companies and power users demand on grids stability is highly increased. Currently usual methods of insulator monitoring are ESDD (equivalent salt deposit density), experiment and on-line detecting of leakage current [. But they can't fully meet our requirements. Now this paper will present a new method, which is made correlation analysis by harmonic analysis based on two ends of the existing lines to the data acquisition apparatus of voltage and current signals. Without additional hardware devices online monitoring of insulator surface contamination can be achieved.

• Periodical: Applied Mechanics and Materials (Volume 521)
• Pages: 339-342
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.521.339
• Online since: February 2014
• Authors: Yu Sheng Quan, Ning Chen, Shai Gen Han, Pu Xin Shi
• Keywords: Correlation Analysis, Insulators Contamination, On-Line Monitoring, Transmission Line

References

[1] Yuanhui Hu, Ji Lin, Xiaoping Kang, Zhenhua Zheng. Filthy State Monitoring Status of Transmission Lines[J]. Electric Switchgear, 2011. No. 6, pp.10-12（In Chinese）.

[2] Zhiyi Su. Review and summary of the historical of power grid's pollution flashover accidents and power grid pollution flashover resistance. CERPI （In Chinese）.

[3] Renowden, J ; Richards, C . Monitor predicts flashover of contaminated insulators[J]. Electrical World. , v 210, n 10, pp.39-40, Oct. (1996).

[4] Liping Shi, Yanhua Zhu, Ningtan Zhu. On-line Forecasting Insulator's ESDD with Least Squares Support Vector Machine[J]. High Voltage Apparatus, Vol. 49 No. 4 Apr. 2013, pp.82-85 （In Chinese）.

[5] Xiaochun Chen, Mincong Zheng, Jianhua Li. Aging Characteristics of Silicone Rubber Composite Insulator Sheds Studied by Infrared Spectroscopy[J]. Proceedings of the CSEE, V01. 32, Dec 30 2012, pp.57-63 （In Chinese）.

[6] Qian Gao, Pengfei Ma, Huangyuan Li. Research on the Pollution of the Insulators Based on the Properties of Microwave Radiation[J]. High Voltage Engineering, Vol-32 No. 7, July 2006, pp.25-30 （In Chinese）.

[7] Xingliang Jiang, Qiangfeng Xia. Influence of Contamination to Infrared Imaging Method Detecting Deterioration Insulators[J]. High Voltage Engineering, V01. 36, No. 7, July 31 2010, pp.1619-1625（In Chinese）.

[8] Lei Wang, Chengyuan Zhong. Insulator Leakage Current and Its Analytical Method. Electric Switchgear[J]. （In Chinese）.

[9] Linnan Duanmu. Research on insulator leakage current characteristics. （In Chinese）.
