Design of a Reconfigurable Extendible Real-Time Multi-Bus Simulation System on the Information Flow in the Control Systems

Abstract:

A simulation system on information flow is designed to emulate the data communication on the RS-485 bus, the 1553B bus and the Ethernet bus. This simulation system has a high requirement for the extendibility, and it must have an ability to regulate and reconfigure the information flow on the three buses. To deal with the above problems, the simulation system has to be designed as a reconfigurable extendible real-time multi-bus simulation system. In order to meet the real-time requirements for the simulation of the information flow and the universal property for the most systems, this simulation system must be carried out based on a real-time operating systems (VxWorks) and a common hardware platforms. Firstly, this simulation system will have a total emulation and a whole simulation for the information flow, the communication status, the monitor nodes and the control nodes on each of the three buses. Secondly, this simulation system defines an extendible protocol between the simulation sever and the simulation terminals, and strictly plan the information flow among the simulation terminals to achieve the design requirements of the actual system. And then the simulation system has to own a reconfigure software components and a complete database functions of recording and stacking the data.

• Periodical: Applied Mechanics and Materials (Volume 527)
• Pages: 315-318
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.527.315
• Online since: February 2014
• Authors: Ling Wang*, Bo Mo, Ke Gao, Jin Lin
• Keywords: 1553B, Ethernet, Extendibility, Information Flow, Multi-Bus, Real Time, Reconfigurable, Simulation System, VxWorks

References

[1] Huang Guojian，Wang Xinhua and Lin Chuanglu: Information flow graphical simuIation methods for smart sensors. Journal of Shaanxi University of Science & Technology, Vol. 30-5 (2012), p.109.

[2] Wang Sen, Yang Jianjun and Hu Wei: Research and Application of Information Flow's Time Delay Model of Command and Control System in Antimissile Battle. MODERN DEFENCE TECHNOLOGY, Vol. 39-1 (2011), p.74.

[3] Wang Xi-min and Cai Zhiming: Appliaction of architecture and dedign patterns in acustic information flow simulation software. JOURNAL OF NAVAL UNIVERSITY OF ENGINEERING, Vol. 18-4 (2006), p.65.

[4] Li Yan-ning, Xu Hongwei, Wu Chao and Sun Huyuan: CAN Bus Network Design and Real-time Analysis of Missile System. Journal of Projectiles, Rockets, Missiles and Guidane, Vol. 33-4 (2013), p.59.

[5] Wang Taiyong, Li Bo, Wan shumin and Li Hongwei: Reconfigurable CNC system based on fieldbus. Computer Integrated Manufacturing Systems, Vol. 12-10 (2006), p.1662.

[6] Yang Xixiang, Zhang Weihua and Xiao Kai: Research on the Ground Simulation Test Platform for Control System Based on CAN Bus. CHINESE SPACE SCIENCE AND TECHNOLOGY, Vol. 2-4 (2009), p.38.

[7] Actel Corporation, Core1553BRM v3. 1 Handbook (2010).
