Orientation Estimation for Motion Capture Unit with Significant Motion Interference

Abstract:

The orientation estimation is a critical technique in inertial sensor based motion capture systems. One challenge of the orientation estimation is that it suffers from the acceleration interference due to body segment motion, especially when the acceleration interference is significant. In this paper, we propose a quaternion based orientation estimation algorithm using unscented Kalman filter. In the algorithm, the acceleration interference is taken as an element of the state vector and estimated in the algorithm together with the orientation quaternion, knowing that the acceleration interference can be predicted based on the rotational angular velocity. The experiments were conducted using both computer simulation and in real-world motion scenarios. Both experimental results have shown the effectiveness of the proposed orientation estimation algorithm.

• Periodical: Applied Mechanics and Materials (Volumes 530-531)
• Pages: 155-159
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.530-531.155
• Online since: February 2014
• Authors: Ling Tong Tian, Zhi Pei Huang, Yi Sun, Lian Ying Ji, Guan Hong Tao
• Keywords: Acceleration Interference, Kalman Filter, Motion Capture, Orientation Estimation

References

[1] Jiang Chen, Shuyan Sun, Guanhong Tao, Jiankang Wu, Multi-model Orientation Estimation by Fusion of Micro Sensory Data, APSIPA Annual Summit and Conference, Biopolis, Singapore, pp.923-926, 14-17 December (2010).

[2] Shuyan Sun, Xiaoli Meng, Lianying Ji, Zhipei Huang, Jiankang Wu, Adaptive Kalman Filter for Orientation Estimation in Micro-sensor Motion Capture, 14th International Conference on Information Fusion, 5-8 July 2011 Chicago, Illinois, USA.

DOI: 10.1109/icif.2010.5711994

[3] D. Young, M. J. Ling, D. K. Arvind, Distributed estimation of linear acceleration for improved accuracy in wireless inertial motion capture, IPSN '10 Proceedings of the 9th ACM/IEEE International Conference on Information Processing in Sensor Networks, New York, USA, pp.256-267.

DOI: 10.1145/1791212.1791243

[4] D. Choukroun, I. Y. Bar-Itzhack, Y. Oshman, Novel quaternion Kalman filter, IEEE Transactions on Aerospace and Electronic Systems, 42(1): 174-190, (2006).

DOI: 10.1109/taes.2006.1603413

[5] J. Calusdian, A personal navigation system based on inertial and magnetic field measurements, Ph.D. dissertation, Naval Postgraduate School, Monterey, CA, Sep. (2010).

[6] X. Yun, J. Calusdian, E. R. Bachmann, and R. B. McGhee, Estimation of human foot motion during normal walking using inertial and magnetic sensor measurements, IEEE Trans. Instrum. Meas., vol. 61, no. 7, pp.2059-2072, Jul. (2012).

DOI: 10.1109/tim.2011.2179830
