Evaluation of Surface Defect Area in Metal Based on Infrared Thermal Image

Abstract:

A method to evaluate surface defects, size of metal plate was put forward base on infrared thermography and time sequence images features. Put 45# steel plate as the object, firstly, time-sequence images in cooling process was got based on infrared thermography technology; Secondly, according to the change features of gray value in normal area and defect area of time sequence images, an identification was made to tell in which image the different factors exists. Finally, combined statistical differences between normal and defect area with image processing techniques to achieve the defect area evaluation. On the basis of laboratory studies, trials of 45# steel sheet were carried out in laboratory and the expected goals were reached. Proposed method enables the average relative errors for each evaluated defect area are less than 7 percent. which can provide a useful reference for the evaluation of defect area of infrared nondestructive testing field.

• Periodical: Applied Mechanics and Materials (Volumes 530-531)
• Pages: 171-174
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.530-531.171
• Online since: February 2014
• Authors: Zheng Ping Liu*, Lin Hai Hu, Jian Min Zhou, Li Cai
• Keywords: Defect Evaluation, Image Processing, Infraredthermography, Time Sequence Images

References

[1] N. Biju,N. Ganesan C.V. Krishnamurthy, et al. Frequency Optimization for Eddy Current Thermography [J]. NDT & E International , 2009, 42(5): 415-420.

DOI: 10.1016/j.ndteint.2009.01.011

[2] Yupeng Tian, Keyin Zhou, et al. Research on Quantitative Evaluation of Infrared Thermography [J]. Chinese Journal of Scientific Instrument, 2008, 11(11): 44-49, (in Chinese).

[3] Hui Liu, Junyan Liu. Detection of Contacting Interface-type Defects Using ultrasound lock in Thermography [J]. Optics and Precision Engineering, 2010, 18(3): 653-660, (in Chinese).

[4] Digital Video Broadcasting(DVB). Second Generation Framing Structure, Channel Coding and Modulation Systems for Broadcasting, Interactive Services, News Gathering and Other Broadband Satellite Applications [S]. Proceedings of the IEEE, 2006(1): 210-216.

[5] Xiaoyan Wu, Yingjie Yu, Lijun Lv. Review on Non-destructive Detection of Inner Defects of object [J]. Laser＆ Optoelectronics Progress, 2013, 3(11): 50-56, (in Chinese).

DOI: 10.3788/lop50.040002

[6] Changhang Xu, Guoming Chen, Jing Xie. Application of Infrared Thermography Technology in Surface Defects Detection of Products in Metal [J]. Manufacturing Automation, 2009, 10(10): 51-54, (in Chinese).

[7] Changlai Gong. Image Denoising Method Based on Wave Let Transform and Mean Filtering [J]. Opto-Electronic Engineering, 2007. 34(1): 72-75, (in Chinese).

[8] Xinping Guan, Lixing Zhao, Yinggan Tang. Mixed Filter for Image Denoising [J]. Journal of Image and Graphics , 2005，10(3): 332 – 337, (in Chinese).
