The Controlling and the System Optimizing of the Rotary Motion in the Wheel-Changing Device of Light Rail

Abstract:

For the crawling problems of the changing-wheel device,the paper put forward a single-degree-of-freedom spring-quality system of a physical model of crawling motion,and described the model mathematically.Than the paper analyzed the main factors which produced several crawl,and obtained the displacement and velocity response curve of the system model,and coincide with the motion state results of the actual light rail in the changing-wheel library device. The paper built a simplified hydraulic system model of the rotary device,and made simulation analysis for the hydraulic system model through the Matlab,found the main factors which influence the crawling system is driving speed (force),vertical load, system stiffness and system damping,than given some methods which can help restrain the crawling. After the simply analyzed for the characteristics of throttle valve,the paper made some optimization for the original hydraulic system,that is at the hydraulic back oil piping,joining the throttle to the components,which purpose is to increase the effective damping of the system,thus inhibiting system to crawl.This optimization already have been proved through the practical engineering application.

• Periodical: Applied Mechanics and Materials (Volume 533)
• Pages: 78-81
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.533.78
• Online since: February 2014
• Authors: Shao Dong Wang, Chang Qi Yang
• Keywords: Crawling Motion, Friction Self-Excited, Hydraulic System, Throttle Valve

References

[1] Sultan. Study and computer simulation of crawling mechanism. Lanzhou: (2007).

[2] Xu Lin, Jin Yu. Hydraulic power control system. Chongqing University press, (1996).

[3] Maoyao Wang. Hydraulic transmission and control course. Tianjin University press, (1984).

[4] Donghai Cao, Zesheng Lu. Numerical simulation of stiffness and damping ratio of crawling machine. Machine tool & hydraulics, (2006).

[5] Qinhe Gao. Modeling and Simulation of [J] machine tool & hydraulics analysis into the crawling phenomenon oil throttle speed regulation hydraulic circuit, 2000 (5).
