Equipment Servo System Signal Acquisition Module Design Based on Embedded

Abstract:

Contrary to the difficult for complex equipment in the parallel signal acquisition, thereby affecting the equipment condition monitoring results, Design a parallel signal data acquisition device and its collection method based on embedded system. It can achieve real-time multi-point data collection and analyze parallel signal data acquisition system structure and function, then giving the hardware design of embedded systems based on the chip, including the processes of mass storage system and a plurality of communication method. Realize of the equipment condition monitoring and fault diagnosis based on this.

• Periodical: Applied Mechanics and Materials (Volumes 536-537)
• Pages: 1037-1040
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.536-537.1037
• Online since: April 2014
• Authors: Jing Tong Chen, Shi Yu Sun, Xiu Sheng Duan
• Keywords: Condition Monitoring, Data Acquisition, Embedded

References

[1] TANG Hong-ru. Research on equipment real time maintenance system based on network[J]. Test and Control Technology, 2002(2): 45-49.

[2] ZHANG X L, WANG ZH H, LI Y Y. Communication between DSP and PC based on USB2. 0[J]. Low Voltage Apparatus, 2007, 9: 28-30.

[3] GUAN SH P, YAO Y, LIU H L. Design and application of embedded system network-interface module based on Ethernet[J]. Chinese Journal of Scientific Instrument, 2007, 28(4): 267-270.

[4] LI Qingcheng, LU Tao, LIU Jiaxin. Research of constructing evaluating architecture of embedded database. Computer Engineering and Design, 2008, 29(1): 123-125.
