Study on Measurement of Six-DOF Force/Torque for Loading Experiment on Heavy Load Equipment

Abstract:

According to the requirements of fatigue test of aircraft cabin, large engine and mining machinery for heavy-duty six dimensional generalized force sensors, a new method of using piezoelectric quartz as force-sensitive element on the basis of the theory of heavy force division and equivalent capacity compression is proposed in this study. Furthermore, in order to minimize the force-coupling for the six-dimension force sensor, the optimization objective function is devised and the calculation method for decoupling is also proposed, on the basis of which, the generalized force sensor with high sensitivity, high stiffness, high linearity but light in its weight is designed. At last, the static calibration experiment is carried out the result shows that the sensor has a good ability of heavy force division and capacity for equivalent compression it can be well used in large tonnage six component force loading device and fatigue test system.

• Periodical: Applied Mechanics and Materials (Volumes 543-547)
• Pages: 1115-1118
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.543-547.1115
• Online since: March 2014
• Authors: Yun Lu*, Wei Jia Li, Wen Zhuo Tian, Kai Zhou
• Keywords: Equivalent Capacity Compression, Fatigue Test, Heavy Force Division, Piezoelectric Quartz, Static Calibration Experiment

References

[1] C. C. Nguyen, S. S. Antrazi, Z. L. Zhou, et al.: Analysis and Experimentation of a Stewart Platform-based Force Torque Sensor, International Journal of Robotics and Automation, Vol. 7(1992) No. 3, pp.133-140.

[2] C. Ferraresi, S. Pastorelli, M. Sorb, et al.: Static and Dynamic Behavior of a High Stiffness Stewart Platform-based Force/Torque Sensor, Journal of Robotic Systems, Vol. 12 (1995) No. 12, pp.883-893.

DOI: 10.1002/rob.4620121211

[3] T. A. Dwarakanath, Bhaskar Dasgupta, T, S. Mruthyunjaya: Design and Development of a Stewart Platform based Force-Torque Sensor, Mechatronics, ( 2001) No. 11, pp.793-809.

DOI: 10.1016/s0957-4158(00)00048-9

[4] R. Ranganath, P. S. Nair, T. S. Mruthyunjaya, and A. Ghosal: A Force-torque Sensor Based on a Stewart Platform in a Near-singular Configuration, Mechanism and Machine Theory, Vol. 39 (2004) No. 9, pp.971-998.

DOI: 10.1016/j.mechmachtheory.2004.04.005

[6] T. Liu, Yoshio Inoue, Kyoko Shibata, et al.: A Six-dimension Parallel Force Sensor for Human Dynamics Analysis. Proceedings of 2004 IEEE Conference on Robotics, Automation and Mechatronics (Singapore, 2004), pp.208-212.

DOI: 10.1109/ramech.2004.1438918

[7] Nicholas Krouglicof, Luisa M. Alonso, and William D. Keat: Development of a Mechanically Coupled, Six Degree-of-freedom Load Platform for Biomechanics and Sports Medicine. Proceedings of 2004 IEEE International Conference on Systems, Man and Cybernetics (Hague, Netherlands, 2004), pp.4426-4431.

DOI: 10.1109/icsmc.2004.1401228
