Development of a Force Feedback System for Omni-Directional Telepresence Robot

Abstract:

This paper describes an existing force feedback system for an omni-directional telepresence robot developed by Chungbuk National University and its implementation with force feedback. The method proposed in this paper features force feedback on a joystick in order to reduce the risk caused by the delay between communications and to help a remote user safely adjust the robot when an unexpected situation occurred or obstacle is detected. This method complements the method being used in existing telepresence systems based on remote control, only depends on a camera and ultrasonic sensors to reduce the delay between communications. Additionally, it takes into account the moving speed of the robot. It is shown through experiments that the proposed method can detect obstacles effectively and print out the force feedback suited to a situation using force feedback based on fuzzy control.

• Periodical: Applied Mechanics and Materials (Volumes 548-549)
• Pages: 928-932
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.548-549.928
• Online since: April 2014
• Authors: Jeong Uk Hwang, Tae Hyoung Park
• Keywords: Force Feedback System, Fuzzy Control, Remote Controlled Robot, Telepresence

References

[1] Green, P.S., Telepresence surgery, Engineering in Medicine and Biology Magazine, IEEE pp.324-329 vol. 14, (1995).

[2] Schultz, R.J., Telepresence mobile robot for security applications, Industrial Electronics, Control and Instrumentation pp.1063-1066 vol. 2, (1991).

[3] Agrawal, S.K.; Xi Chen ; Ragonesi, C. ; Galloway, J.C., Training Toddlers Seated on Mobile Robots to Steer Using Force-Feedback Joystick, Haptics, IEEE Transactions on , 376 - 383, (2012).

DOI: 10.1109/toh.2011.67

[4] Park, J.B.; Lee, B. h Reflective force integration method for nonautonomous mobile robot control", Robotics and Automation, 2004. Proceedings. ICRA , 04. 2004 IEEE International Conference on , 3950 - 3955 Vol. 4.

DOI: 10.1109/robot.2004.1308886

[5] Fattouh, A. ; Sahnoun, M. ; Bourhis, G. Force feedback joystick control of a powered wheelchair: preliminary study, Systems, Man and Cybernetics, 2004 IEEE International Conference on, 2640-2645 vol. 3 , (2004).

DOI: 10.1109/icsmc.2004.1400729

[6] Takemoto, A.; Yano, K. ; Terashima, K. Obstacle avoidance control system of rotary crane using proposed haptic joystick, Eurohaptics Conference, 2005 and Symposium on Haptic Interfaces for Virtual Environment and Teleoperator Systems, 2005. World Haptics 2005. First Joint , 662-663, (2005).

DOI: 10.1109/whc.2005.101

[7] Ae-Kyoung Ko; Joon-Young Choi, A haptic interface using a force-feedback joystick, SICE, 2007 Annual Conference , 202 - 207, (2007).

DOI: 10.1109/sice.2007.4420977

[8] SAEED B. NIKU; Introduction to robotics : analyis, systems, applications.

[9] S. Kodagoda, E.A.S.M. Hemachandra, P.G. Jayasekara, R.L. Peiris, A.C. De Silva and Rohan Munasinghe, Obstacle Detection and Map Building with a Rotating Ultrasonic Range Sensor using Bayesian Combination,, Information and Automation, (2006).

DOI: 10.1109/icinfa.2006.374159

[10] Akihisa Ohya, Yoshiaki Nagashima and Shin'chi Yuta, Exploring Unknown Environment and Map Construction Using Ultrasonic Sensing of Normal Direction of Walls, Inst. of Inf. Sci. & Electron., Tsukuba Univ., Ibaraki, Japan 485 - 492 vol. 1, (1994).

DOI: 10.1109/robot.1994.351251
