Characterisation of the Shear Stud-Concrete Connection Using Finite Element Analysis

Abstract:

The degradation of the connection between shear studs and concrete is a complicated phenomenon that depends on many factors, including; interfacial properties, concrete crushing and steel yielding. The purpose of this paper is to outline the scope and methodology of the research project being undertaken to characterise the shear stud-concrete interface of a composite beam using finite element analysis. A mesoscopic model will be created for a section of the interface. With the use of a multi-scale approach, the mesoscopic model will be incorporated into a global model. The influence of steel roughness and mechanical properties will be included. Concrete is to be modelled as heterogeneous, comprising discrete regions of aggregate, cement matrix, and an interfacial transition zone (ITZ). The effect of the ITZ will be taken into account using a zero thickness cohesive element. Experimental testing using a push-up rig is to be conducted to verify the numerical models. The ultimate aim is to develop a simplified representation of the shear stud-concrete interface that can be used in a large scale finite element model of a composite member to correctly capture the behaviour of the shear stud-concrete interface in the elastic and inelastic state.

• Periodical: Applied Mechanics and Materials (Volume 553)
• Pages: 570-575
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.553.570
• Online since: May 2014
• Authors: Daniel John Lowe*, Raj Das, George Charles Clifton, Namasivayam Navaranjan
• Keywords: Bond, Composite, Concrete, Multi-Scale, Stud

References

[1] Liu Y, Xin H, He J, Xue D, Ma B. Experimental and analytical study on fatigue behavior of composite truss joints. Journal of Constructional Steel Research. 2013; 83: 21-36.

DOI: 10.1016/j.jcsr.2012.12.020

[2] Mirza O, Uy B. Effects of the combination of axial and shear loading on the behaviour of headed stud steel anchors. Engineering Structures. 2010; 32(1): 93-105.

DOI: 10.1016/j.engstruct.2009.08.019

[3] Souici A, Berthet JF, Li A, Rahal N. Behaviour of both mechanically connected and bonded steel-concrete composite beams. Engineering Structures. 2013; 49: 11-23.

DOI: 10.1016/j.engstruct.2012.10.014

[4] Dominguez N, Ibrahimbegovic A. A non-linear thermodynamical model for steel-concrete bonding. Computers & Structures. 2012; 106: 29-45.

DOI: 10.1016/j.compstruc.2012.04.005

[5] Shin D-S, Lee H-S, Cho N, editors. Computational study on mechanical behavior of steel-concrete composite by using interface elements. The Mechanical Behavior of Materials X Part 1: 10th International Conference on the Mechanical Behaviour of Materials; 2007; Laubisrutistr. 24, Stafa-Zuerich, CH-8712, Switzerland: Trans Tech Publications Ltd.

[6] Banholzer B, Brameshuber W, Jung W. Analytical simulation of pull-out tests - The direct problem. Cement and Concrete Composites. 2005; 27(1): 93-101.

DOI: 10.1016/j.cemconcomp.2004.01.006

[7] Ayoub A. A force-based model for composite steel - Concrete beams with partial interaction. Journal of Constructional Steel Research. 2005; 61(3): 387-414.

DOI: 10.1016/j.jcsr.2004.08.004

[8] Daoud A, Maurel O, Laborderie C. 2D mesoscopic modelling of bar–concrete bond. Engineering Structures. 2013; 49: 696-706.

DOI: 10.1016/j.engstruct.2012.11.018

[9] Lam D, El-Lobody E. Behavior of headed stud shear connectors in composite beam. Journal of Structural Engineering. 2005; 131(1): 96-107.

DOI: 10.1061/(asce)0733-9445(2005)131:1(96)

[10] Hanswille G, Porsch M. Lifetime oriented design concepts of steel-concrete composite structures subjected to fatigue loading. Engineering Foundation Conferences; USA, Colorado2008.

DOI: 10.1061/41142(396)2

[11] Qu H, Chen G, editors. Numerical simulation of different-shaped random aggregates' influence on concrete's compression strength. 7th International Conference on Fracture and Strength of Solids, FEOFS 2007, August 27, 2007 - August 29, 2007; 2008; Urumqi, China: Trans Tech Publications.

DOI: 10.4028/www.scientific.net/amr.33-37.623

[12] Agioutantis Z, Chatzopoulou E, Stavroulaki M. A numerical investigation of the effect of the interfacial zone in concrete mixtures under uniaxial compression the case of the dilute limit. Cement and Concrete Research. 2000; 30(5): 715-23.

DOI: 10.1016/s0008-8846(00)00240-4

[13] Häfner S, Eckardt S, Luther T, Könke C. Mesoscale modeling of concrete: Geometry and numerics. Computers & Structures. 2006; 84(7): 450-61.

DOI: 10.1016/j.compstruc.2005.10.003

[14] Qureshi J, Lam D, Ye J. Effect of shear connector spacing and layout on the shear connector capacity in composite beams. Journal of Constructional Steel Research. 2011; 67(4): 706-19.

DOI: 10.1016/j.jcsr.2010.11.009

[15] Tahmasebinia F, Ranzi G, Zona A. Probabilistic three-dimensional finite element study on composite beams with steel trapezoidal decking. Journal of Constructional Steel Research. 2013; 80: 394-411.

DOI: 10.1016/j.jcsr.2012.10.003
