Automated High Quality Isosurface Modeling Technique for Iterative Two-Phase Problems

Abstract:

While smooth isosurface and the subsequent body mesh construction is a well-developed modeling technique and widely used in medical imaging and engineering modeling, it is rarely performed in transient analysis and other iterative procedures due to relatively high computational cost. Voxelized modeling is often used as an alternative for simplicity at a cost of numerical accuracy. To overcome this problem, an isosurface modeling technique is developed in this paper to enable its seamless integration into iterative processes. This approach involves a rapid construction of closed isosurfaces using the Marching Cubes methods and a selective clean-up operation to smooth the surface mesh. This technique generates high quality isosurface meshes with clearly defined 3D domains and boundaries, which in turn provide a suitable foundation for the finite element analysis of two-phase problems. Its robustness, flexibility and suitability for applications in medical imaging and topology optimization are also demonstrated in this paper.

• Periodical: Applied Mechanics and Materials (Volume 553)
• Pages: 818-823
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.553.818
• Online since: May 2014
• Authors: Che Cheng Chang*, Qing Li
• Keywords: Isosurface, Level Set, Tetrahedral Mesh Generation, Two-Phase Modeling

References

[1] Zhou, S., W. Li, and Q. Li, Level-set based topology optimization for electromagnetic dipole antenna design. Journal of Computational Physics, 2010. 229(19): pp.6915-30.

DOI: 10.1016/j.jcp.2010.05.030

[2] Edelsbrunner, H. and N.R. Shah, Incremental Topological Flipping Works for Regular Triangulations. Algorithmica, 1996. 15: pp.223-241.

DOI: 10.1007/bf01975867

[3] Si, H. and K. Gaertner. Meshing Piecewise Linear Complexes by Constrained Delaunay Tetrahedralizations. in 14th International Meshing Roundtable. (2005).

DOI: 10.1007/3-540-29090-7_9

[4] Si, H. On Refinement of Constrained Delaunay Tetrahedralizations. in 15th International Meshing Roundtable. (2006).

DOI: 10.1007/978-3-540-34958-7_29

[5] Fang, Q. and D. Boas. Tetrahedral mesh generation from volumetric binary and gray-scale images. in IEEE International Symposium on Biomedical Imaging 2009. (2009).

DOI: 10.1109/isbi.2009.5193259

[6] Lorensen, W.E. and H.E. Cline, Marching cubes: A high resolution 3D surface construction algorithm. SIGGRAPH Comput. Graph., 1987. 21(4): pp.163-169.

DOI: 10.1145/37402.37422

[7] Labelle, F. and J.R. Shewchuk, Isosurface stuffing: fast tetrahedral meshes with good dihedral angles, in ACM SIGGRAPH 2007, ACM: San Diego, California. p.57.

DOI: 10.1145/1275808.1276448

[8] Wang, J. and Z. Yu, Feature-sensitive tetrahedral mesh generation with guaranteed quality. Computer-Aided Design, 2012. 44(5): pp.400-412.

DOI: 10.1016/j.cad.2012.01.002

[9] Cadman, J., et al., Bioinspired lightweight cellular materials-understanding effects of natural variation on mechanical properties. Mater Sci Eng C Mater Biol Appl, 2013. 33(6): pp.3146-52.
