Topology Optimization of Photonic Band Gap Crystals

Abstract:

This paper proposes a new topology optimization algorithm based on the bi-directional evolutionary structural optimization (BESO) method for the design of photonic band gap crystals. The photonic crystals are assumed to be periodically composed of two given dielectric materials. Based on the finite element analysis, the proposed BESO algorithm gradually re-distributes dielectric materials within the unit cell until the resulting photonic crystals possess a maximal band gap at the desirable frequency level. Numerical examples for both transverse magnetic (TM) and transverse electric (TE) polarizations are presented, and the optimized photonic crystals exhibit novel patterns markedly different from traditional designs of photonic crystals.

• Periodical: Applied Mechanics and Materials (Volume 553)
• Pages: 824-829
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.553.824
• Online since: May 2014
• Authors: Xiao Dong Huang*, Shi Wei Zhou, Yi Min Xie, Qing Li
• Keywords: Bi-Directional Evolutionary Structural Optimization, Photonic Band Gap, Topology Optimization

References

[1] J. G. Fleming, S. -Y. Lin, I. El-Kady, R. Biswas, and K. M. Ho, All-metallic three-dimensional photonic crystals with a large infrared bandgap, Nature 417, 52-55 (2002).

DOI: 10.1038/417052a

[2] J. D. Joannopoulos, S. G. Johnson, J. N. Winn, and R. D. Meade, Photonic Crystals: Molding the Flow of Light (Princeton University Press, 2008).

[3] M. P. Bendsøe and N. Kikuchi, Generating optimal topologies in structural design using a homogenization method , Comp. Meth. Appl. Mech. Eng. 71, 197-224 (1988).

DOI: 10.1016/0045-7825(88)90086-2

[4] M. P. Bendsøe, Optimal shape design as a material distribution problem, Struct. Opt. 1, 193-202 (1989).

[5] M. Zhou and G. I. N. Rozvany, DCOC – an optimality criteria method for large systems, Part I: Theory. , Struct. Opt. 5, 12-25 (1992).

DOI: 10.1007/bf01744690

[6] Y. M. Xie and G. P. Steven, Evolutionary Structural Optimization (Springer, London, 1997).

[7] X. Huang and Y. M. Xie, Evolutionary Topology Optimization of Continuum Structures: Methods and Applications (John Wiley & Sons, Chichester., 2010).

[8] J. A. Sethian and A. Wiegmann, Structural boundary design via level set and immersed interface method,. J. Comp. Phys. 163, 489-528 (2000).

DOI: 10.1006/jcph.2000.6581

[9] M. Y. Wang, X. M. Wang, and D. M. Guo, A level set method for structural topology optimization, Comp. Meth. Appl. Mech. Eng. 192, 227-246 (2003).

[10] O. Sigmund and K. Hougaard, Geometric properties of optimal photonic crystals, Phy. Rev. Lett. 100, 153904 (2008).

DOI: 10.1103/physrevlett.100.153904

[11] H. Men, N. C. Nguyen, R. M. Freund, P. A. Parrilo, and J. Peraire, Bandgap optimization of two-dimensional photonic crystals using semidefinite programming and subspace methods, J. Comput. Physics 229, 3706-3725 (2010).

DOI: 10.1016/j.jcp.2010.01.023

[12] C. Y. Kao, S. Osher, and E. Yablonovitch, Maximizing band gaps in two-dimensional photonic crystals by using level set methods, Appli. Physics B 81, 235–244 (2005).

DOI: 10.1007/s00340-005-1877-3

[13] J. Jin, The Finite Element Method in Electromagnetics, 2nd ed. ed. (John Wiley & Sons, Inc., 2002).

[14] X. Huang, Z. H. Zuo, and Y. M. Xie, Evolutionary topology optimization of vibrating continuum structures for natural frequencies, Comp. & Struct. 88, 357-364 (2010).

DOI: 10.1016/j.compstruc.2009.11.011

[15] X. Huang and Y. M. Xie, Bi-directional evolutionary topology optimization of continuum structures with one or multiple materials, Comp. Mech. 43, 393-401 (2009).

DOI: 10.1007/s00466-008-0312-0
