Buckling-Induced Retraction of Structured Spherical Shell under Pressure

Abstract:

This paper investigates the reversible retraction of a spherical perforated shell that is made from nonlinear soft material. The buckling and post-buckling simulation in Abaqus shows the skeleton ligaments of such a buckliball rotate in the beginning and buckle thereafter, resulting in the shrinkage and encapsulation of the whole structure in the final stage. We used dynamic-explicit method in the simulation and its superiority over others is verified by obtaining correct buckling patterns efficiently and stably.

• Periodical: Applied Mechanics and Materials (Volume 553)
• Pages: 842-846
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.553.842
• Online since: May 2014
• Authors: Sen Lin, Shi Wei Zhou*, Yi Min Xie, Xiao Dong Huang, Qing Li
• Keywords: Buckliball, Buckling, Post-Buckling Analysis, Soft Material
