The Automatic Calculation of Cumulative Lamination and Analysis of the Structural Static Rigidity of Bike Frame Made of Carbon Fiber Composite

Abstract:

This paper discusses the process of calculating the lay-up configuration and structural stiffness of carbon fiber composite bike frame. First, a program is written in ANSYS macro language to calculate the lay-up configuration of the composite. The user only has to input the geometry, fiber orientation and sequence of individual layer, according to the original shop drawing. The program will then calculate the lay-up configuration of all the details for the whole structure automatically, and create the finite element model for ANSYS. The stiffness is then analyzed according to the product specification, and also compared with test result to evaluate the validation of the model. This automated process can accelerate the development time frame, and also work as the basis of parametric model for future design optimization.

• Periodical: Applied Mechanics and Materials (Volume 563)
• Pages: 13-20
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.563.13
• Online since: May 2014
• Authors: Ching Hui Tai, Chun Ho Yin
• Keywords: Bike Frame, Carbon Composite, Numerical Analysis

References

[1] Song Yijun，The rigidity analysis on bike frame of composite material, Master Thesis, Department of Mechanical and Electrical Engineering, National Sun Yat-sen University, Kaohsiung, Taiwan，2005.

[2] Liao Jiajun，The rigidity analysis on carbon fiber bike frame, Master Thesis, Department of Mechanical Engineering, Feng Chia University, Taichung, Taiwan.

[3] Liu Jinqi, Wu Huangjie, The fiber angel and lamination sequence design of bicycle composite frame, Chinese Mechanical Engineering Society Twenty-sixth National Symposium Anthology, Solid Power and Materials Group, C02-008, Tainan, Taiwan, (2009).

[4] Liu Wenjin, Chen Kuoyuan, Zhou Shangxian, Carbon fiber bicycle frame rigidity reinforcement, Chinese Mechanical Engineering Society Twenty-sixth National Symposium Anthology, Solid Power and Materials Group, C02-009, Tainan, Taiwan, (2009).

[5] T. R. Chandrupatla and A. D. Belegundu, Introduction to Finite Elements in Engineering, 3rd ed., Prentice-Hall, (2002).

[6] M. H. Sadd, Elasticity: Theory, Applications & Numerics, 2nd ed., Academic Press, (2004).

[7] Gibson, R. F., Principles of Composite material Mechanics, New York: McGraw-Hill Inc., (1994).

[8] ANSYS, ANSYS Mechanical APDL Element Reference, The ANSYS Inc., Canonsburg, USA.
