Experiment and Application Study on the Load-Bearing Properties of Shallow Arch Circular Concrete Filled Steel Tube Support

Abstract:

Shallow arch circular concrete filled steel tube support has a good load-bearing capacity, which is used in soft rock roadway supporting to solve the problem of supporting instability and to reduce the amount of anti-invert excavation. In this paper, concrete filled steel tube supports of Φ168 ×6 are designed according to shallow arch circular concrete filled steel tube structures and their load-displacement curves, ultimate bearing capacity and support failure mode are especially tested in experiment. This shallow arch circular concrete filled steel tube support is also applied in very soft rock roadway supporting of No. 1 mine well of Chaganzhuoer in Xilinhot, Inner Mongolia and proved to be of good supporting effect. The shallow arch circular concrete filled steel tube support is of higher load-bearing capacity and of outstanding advantages in solving extremely soft rock roadway supporting problems, as is proved in both theoretical test and application.

• Periodical: Applied Mechanics and Materials (Volumes 568-570)
• Pages: 1662-1666
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.568-570.1662
• Online since: June 2014
• Authors: Jun Wang, Yan Fa Gao
• Keywords: Concrete Filled Steel Tube Support, Extremely Soft Rock Roadway Supporting, Performance Experiment, Shallow Arch Circular

References

[1] CAI Shaohuai．Modern Steel Concrete Structure（Revised）[M]．Beijing：People's Transportation Press，2007. (In Chinese).

[2] HAN Linhai. Steel Concrete Structure: Theory and Practice[ M] . Beijing: Science Press, 2004. (In Chinese).

[3] GAO Yanfa, WANG Bo, WANG Jun, etc. The property experiment and application of deep well soft rock roadway steel concrete structure. [J]．Chinese Journal of Rock Mechanics and Engineering, 2010，29(s1)：2604-2610. (In Chinese).

[4] WANG Jun, CHEN Feng, LIU Guolei, ZHANG Xizhong. Technological application thousand deep roadway Concrete filled steel tube Support [J]. Tunnel Construction, 2013, 09: 774-778. (In Chinese).

[5] ZHANG Xiaofeng, YAN Wei. Application of Concrete filled steel tube Support in Huafeng Coal Mine deep well. [J]. Coal Mine Machinery, 2011, 07: 194-196. (In Chinese).

[6] GAO Yanfa, WANG Jun, HUANG Wanpeng. Mechanical property experiment and application of straight wall arched Concrete filled steel tube Support. [J]. Tunnel Construction. 2014, 01: 2-6. (In Chinese).

[7] LIU Guolei. Theoretical study on Concrete filled steel tube Support performance and soft rock roadway reinforced load support [D]．China University of Mining and Technology (Beijing), 2013. (In Chinese).

[8] Jun Wang, Guang-long Qu, Guo-lei Liu. Supporting technology research of concrete filled steel tubular support in extremely soft roc mining area[J]. Advances in Civil and Industrial Engineering: Applied Mechanics and Materials Vols. 355-356(2013).

DOI: 10.4028/www.scientific.net/amm.353-356.1559

[9] MAO Yongjiang, LI Shaohua, WANG Haibin. Research on the supporting techniques of the main slope well of No. 1Well in Chaganzhuoer. [J]. China Mining Magazine, 2012, 11: 110-112. (In Chinese).
