Study on Machining Mechanism of Glass Using Discrete Element Method

Abstract:

The discrete element method (DEM) is applied to glass micromachining in this study. By three standard tests the discrete element model is established to match the main mechanical properties of glass. Then, indentating, cutting, micro milling process are simulated. Results show that the vertical damage depth is prevented from reaching the final machined surface in cutting process. Tool rake angle is the most remarkable factor influencing on the chip deformation and cutting force. The final machined surface is determined by the minimum cutting thickness per edge. Different cutting thickness, cutter shape and spindle speed largely effect on the mechanism of glass.

• Periodical: Applied Mechanics and Materials (Volume 577)
• Pages: 108-111
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.577.108
• Online since: July 2014
• Authors: Ying Qiu*, Mei Lin Gu, Feng Guang Zhang, Zhi Wei
• Keywords: Discrete Element Method, Glass, Machining Force, Micro-Machining, Size Effect

References

[1] Marzellus grosse Holthaus, Sven Twardy, Julia Stolle, Oltmann Riemer, Laura Treccani, Ekkard Brinksmeier, Kurosch Rezwan, Micromachining of ceramic surfaces: Hydroxyapatite and zirconia, J MATER PROCESS TECH, 212 (2012) p.614–624.

DOI: 10.1016/j.jmatprotec.2011.06.007

[2] K.L. Choo, Y. Ogawa, G. Kanbargi, V. Otra, L.M. Raff, R. Komanduri, Micromachining of silicon by short-pulse laser ablation in air and under water, MAT SCI ENG A-STRUCT, 372(2004) pp.145-162.

DOI: 10.1016/j.msea.2003.12.021

[3] Sathyan Subbiah, Shreyes N. Melkote, Effect of finite edge radius on ductile fracture ahead of the cutting tool edge in micro-cutting of Al2024-T3, MAT SCI ENG A-STRUCT, 474 (2008) p.283–300.

DOI: 10.1016/j.msea.2007.04.116

[4] Muhammad Arif, Mustafizur Rahman, Wong Yoke San, Ultraprecision ductile mode machining of glass by micromilling process, Journal of Manufacturing Processes, 13 (2011) p.50–59.

DOI: 10.1016/j.jmapro.2010.10.004

[5] Takenori Ono, Takashi Matsumura, Influence of tool inclination on brittle fracture in glass cutting with ball end mills, J MATER PROCESS TECH, 202 (2008) pp.61-69.

DOI: 10.1016/j.jmatprotec.2007.08.068

[6] Kevin Foy, Zhi Wei, Takashi Matsumura, Yong Huang, Effect of tilt angle on cutting regime transition in glass micromilling, INT J MACH TOOL MANU, 49(2009) p.315–324.

DOI: 10.1016/j.ijmachtools.2008.10.007

[7] Damien André, Ivan Iordanoff, Jean-luc Charles, Jérome Néauport, Discrete element method to simulate continuous material by using the cohesive beam model, COMPUT METHOD APPL M, 213–216 (2012) p.113–125.

DOI: 10.1016/j.cma.2011.12.002

[8] Wang yufen, Liu liancheng. Quartz glass. Chemical Industry Press, (2006).
