Ionic Distribution in Plasma for the Process of Electron-Beam Physical Vapor Deposition

Abstract:

This paper investigates ionic distribution generated by electron beam (EB) during Physical Vapor Deposition (PVD). EB-PVD has a wide range of applications in thermal barrier coatings (TBCs) due to favorable characteristics compared with other coating processes. EB-PVD is an important material coating method that utilizes electron beams as heat sources to evaporate materials, which are then deposited on a substrate. Therefore EB-induced ionic distribution dominates the quality and thickness of the final coating on the substrate. Assuming the EB-generated plasma to be only a function of radial direction, the steady-state equations of continuity and motion combined with Posson’s equation were utilized to analyze the plasma distributions along the radial direction. The available experimental data are also used to validate the model. The results show that the coating efficiency can be improved by decreasing the ratio of the electron thermal energy to the initial ion energy and increasing the ratio of the initial ion density to the initial electron density. The uniformity of coating can be achieved by reducing the initial ion density.

You might also be interested in these eBooks

Advance Materials Development and Applied Mechanics

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 597)

Pages:

153-156

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.597.153

Citation:

Cite this paper

Online since:

July 2014

Authors:

Ching Yen Ho*, Wen Chieh Wu

Keywords:

Coating, Electron Beam, Ionic Distribution, Physical Vapor Deposition

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] B. Dikshit, M.S. Bhatia, BARC Newsletter 314 (2010) 10-19.

Google Scholar

[2] I. Wane, Etude, réalisation et caractérisation de couches de ferrites destinées à des dispositifs intégrés micro-ondes non réciproques, Thesis, University of Limoges, (2000).

Google Scholar

[3] R. F. Bunshah, Handbook of Deposition Technologies for Films and Coatings, 2nd ed. New Jersey: Noyes Publications, ed. (1994).

Google Scholar

[4] I.M. Sobol, the Monte Carlo Method, Mir, Moscow, (1975).

Google Scholar

[5] P. Aubreton, A. Bessaudou, C. Di Bin, Computational Materials Science 33 (2005) 400-406.

Google Scholar

[6] I.A. Krinberg, G.M. Mladenov, Vacuum 77 (2005) 407-411.

Google Scholar
