Research on Overloading Protection of Permanent Magnetic Coupler in Coal Mine

Abstract:

In this paper, with simulations and experiments analysed by the software of Ansoft Maxwell, research on overloading protection of permanent magnetic coupler in coal mine is carried out and the conclusive curves of mechanical characteristics are plotted through experimental data. The conclusion can be gained from mechanical characteristic curves: when the output value of torque reaches the maximum torque of magnetic coupler, the output torque and speed will drop along with increases of the slip, and the input power value of motor is less than the power value at the time when the motor torque value is at the maximum. It explains that the magnetic coupler has the function for overloading protection.

• Periodical: Applied Mechanics and Materials (Volume 597)
• Pages: 492-497
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.597.492
• Online since: July 2014
• Authors: Wen Qi Yuan*, Yue Liu, Dong Li, Guo Ying Meng
• Keywords: Curves of Mechanical Characteristics, Magnetic Coupler, Overloading Protection

References

[1] Shengjiang Liu. Research on Mine Permanent Magnetic Driving Device[J]. Coal Mine Machinery. 2013, 34(9): 184-185.

[2] Honggang Zhang. Calculation and Analysis of Permanent Magnetic Coupling Losses[D]. Jilin University, (2008).

[3] Kerong Peng. Research on the Structure and Characteristics of Permanent Magnetic Coupling[D]. Harbin Institute of Technology, (2008).

[4] Yong Wang. Magnetic mechanical analysis and design method[M]. Hefei: Hefei University of Technology Press, (2007).

[5] Qi Zhang. Magnetic coupling characteristic test platform design[D]. Dalian Maritime University, (2013).
