Design and Research of LED Intelligent Lighting System

Abstract:

In order to intelligentize the LED lighting systems,this system adopts the Freescale series MC9S08AC16 as the controller, senses the light environment induced by the photoresistor and uses the SS-101 pyroelectric infrared sensors to sense the presence of people. In addition, it uses LM3404 chip to drive LED headlamp unit and by changing the duty cycle of PWM to achieve the switches and automatic adjustment of brightness of LED lights. Experiments show that the light source brightness provided by this system is stable and reliable and the combination of infrared sensing technology and PWM technology achieves the intelligence of LED lights. Moreover, it has high application value.

• Periodical: Applied Mechanics and Materials (Volume 610)
• Pages: 519-522
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.610.519
• Online since: August 2014
• Authors: Xiang Rong Li, Hai Peng Wang*, Guo Shuai Li
• Keywords: Infrared Sensing Technology, Intelligent, LED, MC9S08AC16, PWM Technology

References

[1] Shi Song, Yan Zhang Liu, etc: submitted to Journal of Electrical automation(2009).

[2] Bo Zhang, Hong Zheng, etc: submitted to Journal of Electric drive(2010).

[3] Freescale Semiconductor company, MC9S08AC16 Freescale Semiconductor company product manual, tenth ed., America, (2011).

[4] National Semiconductor company, LM3404National Semiconductor's product manual, second ed., America, (2010).

[5] YiJian Chen: submitted to Journal of light source and lighting( 2012 ).

[6] DongYing Jia, Wei Wang: submitted to Journal of lighting engineering( 2010).
