Modal Analysis for the Fuselage of the New Tube Automatically Benchmarked Equipment Based on ANSYS Workbench

Abstract:

The 3D solid model of the tube automatically benchmarked equipment is built by UG software. With seamless connectivity UG and ANSYS Workbench software, modal analysis of the fuselage of the automatically benchmarked equipment built by ANSYS Workbench software. Then natural frequencies and modal of the lower six orders are obtained, and the vibration weakness of the structure has also been found out. To improve the structure provides a reliable reference
