Type Synthesis of a 1T Symmetric Coupling Mechanism with the Method of Separation and Merger

Abstract:

The structural synthesis is the primary and the most important issue in the process of mechanism creative design. In the paper, Firstly, select a 1T symmetric parallel mechanism, and the constraint and mobility of the branches can be analyzed. With the method of linear combination of the screws, the new branches are constructed. Then, using the measure of separation and merger, parts of the limbs of the parallel mechanism can be replaced by equivalent coupled structures, so corresponding symmetric coupling mechanisms with equal mobility are synthesized. Finally, solving the constraint screws of the branch of the coupling mechanism, in order to prove the hybrid mechanism is full-cycle or not.
