The Simulation Study of Electromagnetic Wave Propagation Characteristics in Closed GIS Tank

Abstract:

Partial discharge (PD) detection using UHF signal is a well known advanced detecting method in GIS and has been actively studied. Numerical simulation using finite difference time domain (FDTD) algorithm is performed to investigate the transmission characteristics of W-M waves excited by partial discharge through straight closed tank of a GIS bus in. The time domain decaying characteristics and frequency domain resonance characteristics is studied in this paper. The simulation results shown that for the closed tank, E-M waves attenuate little during transmission and distribute oscillating in the tank. The distributions are symmetrical at 0 degree and 180 degrees and the energy at the two types of degrees is the same.
