Combined Constructive Solutions for Increasing Cast C-Frame Stiffness of Mechanical Presses

Abstract:

With responsibility as its central element, sustainable development is a concept that calls for permanently increasing information usage while minimising material and energy consumption. Waste – particularly of energy – cannot last, and is evidently not a long-term solution. In the field of machine-tools structures deemed sustainable fulfil their functions for a sufficiently long period of time, while consuming as small as possible amounts of energy and including a small as possible volume of material. In a machine-tool, as in numerous other industrial products, energy consumption in deployment significantly exceeds that of their manufacturing. A conclusive example is that of mechanical presses, machine-tools with long service lives and considerable deployment energy consumption. With increasing stiffness of presses, deployment energy consumption is smaller. Detailed research conducted by the authors has yielded a series of innovative constructive solutions for mechanical press cast C-frames – frames with ribbed lateral walls, frames with pre-stressed front columns and shortened frames – with increased stiffness and minimum additional metal consumption as their main relevant characteristics. The finite element based study of these novel constructive solutions has revealed stiffness increases of 1 to 12 %, significantly depending on the type of constructive solution. The novel solutions can be combined in view of cumulating the obtained positive effects. The paper presents relevant examples of such combined constructive solutions and the results related to stiffness increase obtained by means of the conducted FEA study.

• Periodical: Applied Mechanics and Materials (Volume 657)
• Pages: 455-459
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.657.455
• Online since: October 2014
• Authors: Romeo Cioară*, Ioan Dan
• Keywords: C-Frame, Combined Solutions, Elastic Strain, Innovative Solutions, Press, Stiffness, Sustainable Development, Tensions State

References

[1] G. Atkinson, S. Dietz and E. Neumayer, Handbook of Sustainable Development, Edward Elgar Publishing, (2009).

[2] C. Gheorghe, Ecologic dimensioning of industrial products (in Romanian), Tehnica-Info Publishing, Chişinău, (2009).

[3] B. Wallace, Becoming part of the solution: the engineer's guide to sustainable development, American Council of Engineering Companies, (2005).

[4] V. Tabără and I. Tureac, Machines for cold forming (in Romanian), Didactică şi Pedagogică Publishing, Bucureşti, (1984).

[5] R. Cioară, I. Dan, A.M. Ţîţu and C. Oprean, RO patent application A 2013 00014 (2013).

[6] R. Cioară, I. Dan, A.M. Ţîţu and C. Oprean, RO patent application A 2013 00006 (2013).

[7] I. Dan and R. Cioară, Research on increasing mechanical press C-frame stiffness by shortening. Academic Journal of Manufacturing Engineering. 11, 3 (2013) 120-125.
