About the Friction of the Wiper Windscreen Contact

Abstract:

In order to study the influence parameters for the wiper-windscreen friction, a test system was built, using an assembly of a car plane auto rear window glass, with the electrical motor, the wiper mechanism and also a wiper with a modified arm (by inserting a transducer to measure the friction force, based on tensometric strain gauges). Also on the wiper arm, on the opposite side of the arm/blade connection (located approximatelly at the middle of the blade length) a loading system was mounted. Different loading forces can be applied to the blade contact by gravity by simple changing the mass placed on this system. A large number of experiments were performed for different combinations of the values for the blade oscillating period and for the normal force in dry and wetted conditions for the blade-windscreen contact. The obtained results, reveal a direct correlation of the friction force with the load mass and with the relative speed in the contact (blade moving period). A higher friction occurs for the dry contact. This force has a higher increasing tendency for this contact than for the wetted contact when a stabilisation tendency of the friction force occurs.

You might also be interested in these eBooks

Advanced Concepts in Mechanical Engineering I

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 658)

Pages:

335-338

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.658.335

Citation:

Cite this paper

Online since:

October 2014

Authors:

Ilie Musca*, Gavril Musca, Dumitru Cristian Vultur, Bogdan Vasile Ungurean

Keywords:

Experimental Device, Friction, Windscreen, Wiper

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] G. Bodai, T. J. Goda. Sliding friction of wiper blade: Measurement, FE modeling and mixed friction simulation. Tribology International, Volume 70, February 2014, Pages 63–74.

DOI: 10.1016/j.triboint.2013.07.013

Google Scholar

[2] Y. Fujii. Method for measuring transient friction coefficients for rubber wiper blades on glass surface. Tribology International, Volume 41, Issue 1, January 2008, Pages 17–23.

DOI: 10.1016/j.triboint.2007.04.003

Google Scholar

[3] D. -C. Vultur, Graduate paper, University Stefan cel Mare, Suceava, Romania, (2012).

DOI: 10.18662/lumproc.81

Google Scholar

[4] B. -V. Ungurean, Graduate paper, University Stefan cel Mare, Suceava, Romania, (2012).

DOI: 10.18662/lumenlaw.6

Google Scholar
