Friction Torque Measurement in Partial Hybrid S-C Angular Contact Ball Bearings

Abstract:

To monitor the friction torque evolution in tandems of angular contact ball bearings, a new testing device is developed. New partial hybrid bearings from 7206C series are obtained by combining 8 steel balls with 4 silicon nitride balls of the same diameter equally spaced in the cage, these bearings being denoted hereafter as 8S-4C type. For comparison, tests are carried-out also on conventional all-steel bearings and hybrid bearings with all the steel balls replaced by silicon nitride balls. The equilibrium temperature of the all-steel, hybrid and 8S-4C ball bearings is determined by tests. At high speed and light axial load, the 8S-4C ball bearings withstand to an oil shut-off test of one minute, while the similar all-steel bearings seized. The 8S-4C partial hybrid ball bearings can be an advantageous solution comparative to more expensive all hybrid bearings, avoiding the scuffing due to the self-healing effect induced by the higher hardness of the silicon nitride balls.

• Periodical: Applied Mechanics and Materials (Volume 658)
• Pages: 339-344
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.658.339
• Online since: October 2014
• Authors: Viorel Paleu*, Ioan Damian, Cristel Stirbu
• Keywords: Friction Moment, Hybrid Ball Bearings, Oil Mist Lubrication, Silicon Nitride, Test Rig

References

[1] H. Aramaki, Y. Shoda, Y. Morishita, T. Sawamoto, The Performance of Ball Bearings With Silicon Nitride Ceramic Balls in High Speed Spindles for Machine Tools, ASME J. Tribol., 110 (1988) 693-698.

DOI: 10.1115/1.3261715

[2] V. Paleu, D. Nelias, On Kerosene Lubrication of Hybrid Ball Bearings, The Annals of Dunarea de Jos, University of Galati, VIII (2007) 123-129, online to http: /www. om. ugal. ro/AnnalsFasc8Tribology/pdf/2007/8-Dipre07_MT-12-Paleu. pdf.

[3] V. Paleu, Friction Moment Evolution in The Running-In Period of High-Speed Angular Contact Ball Bearings, Mechanical Testing and Diagnosis, 2-II (2012).

[4] A. Gabelli, L. Kahlman, Bearings that heal themselves, Evolution - the business and technology magazine from SKF, No. 3, (1999), online to www. skf. com.

[5] W. Wang, P.L. Wong, F. He, G.T.Y. Wan, Experimental Study of the Smoothing Effect of a Ceramic Rolling Element on a Bearing Raceway in Contaminated Lubrication, Tribol. Lett., 28 (2007) 89-97, DOI 10. 1007/s11249-007-9251-8.

DOI: 10.1007/s11249-007-9251-8

[6] V. Paleu, Sp. Cretu, D. Nelias, Behavior of Hybrid and All-Steel Angular Contact Ball Bearings in Oil Shut – Off Conditions: Experimental and Theoretical Result, S.T.L.E. ' 58th Annual Conference, (April-May 2003), New York.
