Study of Temperature Evolution and Metal Flow of 6005A Aluminum Alloy during Indirect Extrusion

Abstract:

A numerical model has been build up to study temperature evolution and metal flow for the indirect extrusion of 6005A aluminium alloy. Model validation was carried out by comparison between experiments and simulations. Results show a good agreement with each other. The influence of the extrusion parameters on the profile temperature and metal flow were studied according to the real industrialized process. It was found that the profile temperature increases with the ram speed as well as the peak load of the total press force. However, a too slow extrusion process would cause increasing of the total force at the end of the extrusion because of heat dissipation to the environment. In addition the dead metal zone at the top of the billet was shrunk during the extrusion process. The ram speed would have little influence on the distribution and shape changing of dead metal zone. Once the extrusion went into steady stage, the strain rate of metal flow would keep a stable situation relatively.

• Periodical: Applied Mechanics and Materials (Volumes 66-68)
• Pages: 164-169
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.66-68.164
• Online since: July 2011
• Authors: Ji Sen Qiao, Fi Li, Tian Dong Xia
• Keywords: Aluminium Alloy, Finite Element Model (FEM), Indirect Extrusion, Metal Flow, Strain Rate

References

[1] Parvizian, F., Kayser: Thermomechanical modeling and simulation of aluminum alloy behavior during extrusion and cooling. J. Mater. Process. Tech. Vol. 209 (2009), p.876–883.

DOI: 10.1016/j.jmatprotec.2008.02.076

[2] Sano Hideo, Ishikawa Takashi: Study on metal flow in extruded billet. Proceedings of the eighth international aluminum extrusion technology seminar, (2004), pp.47-53.

[3] Roy, M.J., Klassen, R.J., Wood: Evolution of plastic strain during a flow forming process. Journal of Materials Processing Technology. Vol. 2 0 9 (2009), p.1018–1025.

DOI: 10.1016/j.jmatprotec.2008.03.030

[4] Farhoumand, A., Ebrahimi, R: Analysis of forward–backward-radial extrusion process. Materials and Design. Vol. 30 (2009), p.2152–2157.

DOI: 10.1016/j.matdes.2008.08.025

[5] Schikorra, M., Donati, L., Tomesani, L., Kleiner, M: The role of friction in the extrusion of AA6060 aluminum alloy process analysis and monitoring. Journal of Materials Processing Technology. Vol. 191 (2007), p.288–292.

DOI: 10.1016/j.jmatprotec.2007.03.096

[6] Wang, L.G., Sun, X.P., Huang, Y: Friction analysis of microcosmic elastic-plastic contact for extrusion forming. Journal of Materials Processing Technology. Forum Vol. 187–188 (2007), p.631–634.

DOI: 10.1016/j.jmatprotec.2006.11.046

[7] Schikorra, M., Donati, L., Tomesani, L., Tekkaya, A.E.: Microstructure analysis of aluminum extrusion: Prediction of microstructure on AA6060 alloy. Journal of Materials Processing Technology. Vol. 2 0 1 (2008), p.156–162.

DOI: 10.1016/j.jmatprotec.2007.11.160

[8] Takahashi M.: Isothermal extrusion of Aluminium alloys. Proceedings of the eighth international aluminum extrusion technology seminar. (2004) pp.1-10.

[9] Sheppard, T., Nature of friction in extrusion process and its effect on material flow. Journal of Materials Processing Technology. Vol. 19 (2003), p.837–846.

DOI: 10.1179/026708303225004422

[10] Nagasekhar, A.V., Yoon, S.C.: An experimental verification of the finite element modeling of equal channel angular pressing. Journal of Computational Materials Science Vol. 46 (2009), pp.347-351.

DOI: 10.1016/j.commatsci.2009.03.018

[11] Flitta, I., Sheppard, T.: Temperature changes and their effect on deformation during extrusion using FEM. Proceedings of the eighth international aluminum extrusion technology seminar (2004), pp.269-283.

[12] Sellars, C.M., Zhu, Q.: Microstructural modelling of aluminium alloys during thermomechanical processing. Journal of Materials Science and Engineering Vol. 280 (2000), p.1–7.

DOI: 10.1016/s0921-5093(99)00648-6
