Non-Invasive Test of Soft Tissue for Tissue Reaction in Needle Biopsy

Abstract:

Needle biopsy is a widely used medical procedure in which a tissue sample is cut and removed by needle for examination to identify and diagnose cancer and other diseases. Predictions of soft tissue deformation and reaction caused by needle insertion are important for the accuracy of this procedure. In this paper, in order to aquire the properties of soft tissue, indentation experiments of porcine livers are performed as non-invasive test to measure the force response depending on time in various indentation depth and indentation velocities conditions. A nonlinear least square method on Matlab have been created to fit the indentation results. According to the experimental and fitting indentation force-time curves, the coefficients of Neo-Hookean model and Kelvin model which are selected to develop the nonlinear model of porcine liver are acquired . Finally, a finite element model of liver based on experimental data is finally developed and succeeds in simulating the stress relaxation character and force-time curve. This finite element model and methodology can be used to investigate soft tissue reaction in needle biopsy.

• Periodical: Applied Mechanics and Materials (Volumes 66-68)
• Pages: 983-988
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.66-68.983
• Online since: July 2011
• Authors: M. Liu, Q.H. Zhang, L.Y. Gao, Xue Mei Qin
• Keywords: Hyperelasticity, Indentation, Needle Biopsy, Tissue Properties, Viscoelasticity

References

[1] N. Abolhassani R.V. Ratel and F. Ayazi: Minimization of needle deflection in robot-assisted percutaneous therapy. The International Journal of Medical Robotics and Computer Assisted Surgery(2007), pp.140-148.

DOI: 10.1002/rcs.136

[2] S.P. DiMaio and S.E. Salcudean: Needle Insertion Modeling and Simulation. IEEE Transactions on Robotics and Automation. Vol. 19. No. 5 (2003).

DOI: 10.1109/tra.2003.817044

[3] M. Heverly and P. Dupont: Trajectory optimization for dynamic needle insertion. IEEE International Conference on Robotics and Automation (Barcelona, Spain, April18-22, 2005).

DOI: 10.1109/robot.2005.1570349

[4] M.P. Ottensmeyer: Minimally invasive instrument for in vivo measurement of solid organ mechanical impedance. (Ph.D. Thesis. MIT 2001).

[5] Y.C. Fung: Biomechanics: mechanical properties of living tissues. 2. ( Springer-Verlag Inc; New York, USA 1993).

[6] B.M. Ahn: Characterization of Viscoelastic Properties of Intra-Abdominal Organs from In vitro Indentation Experiments and Inverse Finite Element Parameter Optimization. (Master's Thesis. Korea Advanced Institute of Science and Technology 2006).

[7] B.M. Ahn and J. Kim: Investigating the needle dynamic response during insertion into soft tissue. Proceedings of the Institution of Mechanical Engineers, Part H: Journal of Engineering in Medicine 224(4): 531-540.

DOI: 10.1243/09544119jeim698

[8] E. Samur, M. Sedef, C. Budogan, L. Avtan and O. Duzgun: A robotic indenter for minimally invasive measurement and characterization of soft tissue response. Medical Image Analysis Vol. 11 (2007) p.361–373.

DOI: 10.1016/j.media.2007.04.001
