Electrical Characterisation of Highly Doped Triangular Silicon Nanowires

Abstract:

A top-down silicon nanowire fabrication using a combination of optical lithography and orientation dependent etching (ODE) has been developed using <100> Silicon-on Insulator (SOI) as the starting substrate. Initially, the samples were doped with phosphorus using the diffusion process resulting in carrier concentration of 2 x 10¹⁸ cm^-3. After the silicon nanowires were fabricated, they were measured using a dual configuration method which is similar to the four-point probe measurement technique to deduce its resistivity. The data obtained had suggested that doping distribution in the silicon nanowires were lower and this may have been affected by the surface depletion effect. In addition, with respect to carrier mobility, the effective mobility of electrons extracted using the four-point probe data had demonstrated that the mobility of carriers in the silicon nanowire is comparable with the bulk mobility. This is most probably due to the fact that in this research, the quantum confinement effect on these nanowires is not significant.

• Periodical: Applied Mechanics and Materials (Volume 660)
• Pages: 168-172
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.660.168
• Online since: October 2014
• Authors: Nor F. Za’bah, Kelvin S.K. Kwa, Anthony O'Neill
• Keywords: Dual Configuration, Mobility, Silicon Nanowire, Spin-Coating
