Effect of Die Gap and Punch Travel on Springback in Air V-Bending Process Using Taguchi Method

Abstract:

Springback is a serious problem for the manufacturing industry due to error in the appearance of the final product especially in bending process. Therefore, it's important to investigate the factors that affect the springback behavior . This paper focused on the effect of two parameters, namely die gap and punch travel on springback behavior in air V-die bending process for stainless steel sheet metal. Different values of die gap and punch travel were experimentally used and the final bent angle was measured. Design of Experiments (DoE) was based on Taguchi Method (TM) and the optimum parameters was obtained using signal-to-noise (S/N) ratio. Further analyzed, Analysis of Variance (ANOVA) techniques was carried out to investigate which of the factors are significance on springback effect. The result show that punch travel is the most significance factor than die gap factor based on p-value for punch travel and die gap were 0.003 and 0.045, respectively. From this two factors, punch travel is most considered to reduce springback phenomenon compared to die gap and the effect could be improved through modification of this parameter.

• Periodical: Applied Mechanics and Materials (Volume 660)
• Pages: 317-321
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.660.317
• Online since: October 2014
• Authors: Muhamad Sani Buang, Shahrul Azam Abdullah, Juri Saedon
• Keywords: Die Gap, Punch Travel, Springback, Taguchi Method, V-Die

References

[1] A. Asgari, M. Pereira, B. Rolfe, M. Dingle, and P. Hodgson, submitted to International Conference and Workshop on Numerical Simulation of 3D Sheet Metal Forming Processes, Detroit, USA (2005).

[2] J. A. B. Montevechi, A. F. de Pinho, F. Leal, and F. A. S. Marins, submitted to Proceedings of the 39th conference on Winter simulation, (2007).

[3] S. Thipprakmas and W. Phanitwong, submitted to Journal Materials & Design, (2011).

[4] R. K. Roy, Design of Experiments Using The Taguchi Approach: 16 Steps to Product and Process Improvement: Wiley, (2001).

[5] D. Fei and P. Hodgson, submitted to Journal of Nuclear Engineering and Design, (2006).

[6] R. Srinivasan, D. Vasudevan, and P. Padmanabhan, submitted to Journal of Mechanical Science and Technology, (2013).

[7] S. Kalpakjian and S. R. Schmid, Manufacturing Engineering and Technology. Upper Saddle River, New Jersey: Prentice-Hall, Inc, (2006).
