Retrofitting of Single Unit Tunnel Form Building Using Steel Plate under Out-of-Plane Lateral Cyclic Loading

Abstract:

A one-third scale single unit of 3-storey tunnel form building with foundation beam was designed, constructed and tested under out-of-plane lateral cyclic loading. This building was designed according to BS8110 with no provision for seismic loading. Tunnel form building was initially tested at ±0.01% , ±0.1%, ±0.25%, ±0.5%, ±0.75%, ±1.00%, ±1.25% and ±1.5% drifts until the structure lost its lateral strength (strength degradation). Then, the specimen was repaired and retrofitted using steel plate and angle which was positioned at the wall-slab joints that had suffered severe damages. A similar drift of displacement before retrofitting was repeated for the specimen after being retrofitted. Visual observation of damages, hysteresis loops, stiffness, ductility and equivalent viscous damping (EVD) of the specimen were analyzed and compared before and after retrofitting. The proposed retrofitting technique has increased its lateral strength by 26%. Fewer cracks occurred after retrofitting the specimen compared to before retrofitting. It can be concluded that steel plate and angle can strengthen the wall-slab joint and this method can be used to retrofit the tunnel form building if it had been damaged caused by earthquake excitations.

• Periodical: Applied Mechanics and Materials (Volume 661)
• Pages: 95-99
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.661.95
• Online since: October 2014
• Authors: Shamilah Anudai Anuar*, Nor Hayati Hamid, M.H. Hashim
• Keywords: Damage Evaluation, Out-Of-Plane Loading, Retrofitting, Seismic Loading, Tunnel Form Building

References

[1] Galal, K. and El-Sokkary, . H. Recent advancements in retrofit of RC shear walls. The 14th World Conference on Earthquake Engineering, Beijing, China, October 12-17 (2008).

[2] M.A. Green: High Efficiency Silicon Solar Cells (Trans Tech Publications, Switzerland 1987).

[2] Ghani, K.D., and Hamid, N.H., Experimental Investigation on A non-seismic Precast RC Beam-column Exterior Joint Under Quasi-Static Lateral Cyclic Loading, Safety and Seismic Engineering, WIT Press, ISSN No: 1743-3509, Vol. No. 134, (2013).

DOI: 10.2495/safe130731

[3] Abdul Ghani, K.D., and Hamid, N.H., Comparing the Seismic Performance of Beam-Column Joints with and without SFRC when subjected to Cyclic Loading, Advanced Materials Research, 626, (2013), pp.85-89.

DOI: 10.4028/www.scientific.net/amr.626.85

[4] Hamid, N.H., Hadi, N.D. and Ghani, K.D., Retrofitting of Beam-Column Joint Using CFRP and Steel Plate, World Academy of Science, Engineering and Technology, International Science Index, 84, (2013), pp.783-788.

[5] Jong-Wha Bai. Seismic Retrofit for Reinforced Concrete Building Structures. Consequence-Based Engineering (CBE) Institute Final Report. Mid-America Earthquake Center, CM-4: Structure Retrofit Strategies. Texas A&M University, August (2003).

[6] Balkaya, C., and Kalkan, E., Nonlinear Seismic Response Evaluation of Tunnel Form Building Structures, Computational Structural Journal, 81, (2002), pp.153-165.

DOI: 10.1016/s0045-7949(02)00434-0

[7] Yuksel, S. B and Kalkan, E. Behaviour of Tunnel Form Building Under Quasi-Static Cyclic Lateral Loading, Structural Engineering and Mechanics, Vol. 4, No. 1. (2012), 26-33.

DOI: 10.12989/sem.2007.27.1.099

[8] Hamid, N.H., and Masrom, M. A., Seismic Performance of Wall-Slab Joints in Industrialized Building System (IBS) Under Out-Of-Plane Reversible Cyclic Loading, IACSIT International Journal of Engineering and Technology, Vol. 4, No. 1. (2012), 26-33.

DOI: 10.7763/ijet.2012.v4.313

[9] Al-Aghabari, A., Hamzah, S.H., Hamid, N.H. and Rahman, N. Structural Performance of Two Types Wall Slab Connection Under Out-of-Plane Lateral Cyclic Loading, Journal of Engineering Science and Technology, Vol. 7, No. 2. (2012), 177-194.

[10] Anuar, S.A., Hamid, N.H. and Hashim, M.H. Comparison of Seismic Behaviour for a Single Unit Tunnel Form RC Building Before and After Repaired, Advanced Material Research, Vol. 905, (2014), pp.254-258.

DOI: 10.4028/www.scientific.net/amr.905.254
