A Novel Rectenna Design with DGS Filters for Low-Power Energy Transfer

Abstract:

A high efficiency rectifying antenna (rectenna) is designed at 5.8 GHz by using defected ground structure (DGS) filters for low-power energy transfer. A slot-coupled patch antenna is used as a receiving antenna with a high gain of 8.2dB. A DGS low-pass filter at the input port of the rectifying circuit is used to suppress the high order harmonics by 20dB. A DGS dc-pass filter is designed to block the AC signal from transmitting to the load. Both of the antenna and the filters are simulated by the full wave EM analysis software of HFSS. The RF-DC conversion efficiency of 51.8% is obtained when the received power is as low as 3mW.

• Periodical: Applied Mechanics and Materials (Volumes 668-669)
• Pages: 787-790
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.668-669.787
• Online since: October 2014
• Authors: Shuang Bing Liu
• Keywords: Conversion Efficiency, DGS Filter, Low-Power, Rectenna

References

[1] Brown W. C., The history of power transmission by radio waves, IEEE Trans. Microw. Theory Tech., vol. 32, no. 9, pp.1230-1242, (1984).

[2] E. O. Torres and G. A. Rincon-Mora, Electrostatic energy-harvesting and battery-charging CMOS system prototype, IEEE Trans. Circuits Syst. I, Reg. Papers, vol. 56, no. 9, pp.1938-1948, Sep. (2009).

DOI: 10.1109/tcsi.2008.2011578

[3] Erez Falkenstein, Michael Roberg, and Zoya Popović, Low-Power Wireless Power Delivery. IEEE Trans. Microw. Theory Tech., vol. 60, no. 7, pp.2277-2286, (2012).

DOI: 10.1109/tmtt.2012.2193594

[4] Y. H. Suh and K. Chang, A high-efficiency dual-frequency rectenna for 2. 45- and 5. 8-GHz wireless power transmission, IEEE Trans. Microw. Theory Tech., vol. 50, no. 7, pp.1784-1789, Jul. (2002).

DOI: 10.1109/tmtt.2002.800430

[5] Yu-Jiun Ren and Kai Chang, 5. 8-GHz Circularly Polarized Dual-Diode Rectenna and Rectenna Array for Microwave Power Transmission, IEEE Trans. Microw. Theory Tech., vol. 54, no. 4, p.1495–1502, Apr. (2006).

DOI: 10.1109/tmtt.2006.871362

[6] G. Vera, A. Georgiadis, A. Collado, and S. Via, Design of a 2. 45 GHz rectenna for electromagnetic (EM) energy scavenging, in IEEE Radio Wireless Symp., p.61–64, (2010).

DOI: 10.1109/rws.2010.5434266

[7] Yu Ushijima, Tatsuya Sakamoto, Eisuke Nishiyama, Masayoshi Aikawa, and Ichihiko Toyoda, 5. 8-GHz Integrated Differential Rectenna Unit Using Both-Sided MIC Technology With Design Flexibility. IEEE Trans. Antenna and Propagation, VOL. 61, NO. 6, pp.3357-3360, (2013).

DOI: 10.1109/tap.2013.2247554

[8] J. S. Park, J. S. Yun, and D. Ahn, A design of the novel coupled-line band-pass filter using defected ground structure with wide stop-band performance, IEEE Trans. Microw. Theory Tech., vol. 50, no. 9, p.2037–2043, Sep. (2002).

DOI: 10.1109/tmtt.2002.802313

[9] Mrinal Kanti Mandal and Subrata Sanyal, A Novel Defected Ground Structure for Planar Circuits. IEEE MICROWAVE AND WIRELESS COMPONENTS LETTERS, VOL. 16, NO. 2, pp.93-95, (2006).

DOI: 10.1109/lmwc.2005.863192
