Relationship Study between Bolt Shape and Anchor Performance

Abstract:

Relationship between bolt rib type, rib height, rib spacing and anchor performance have been studied through laboratory drawing test method. Bolt rib type plays a significant impact on the bolt anchor performance. The bigger of the bolt rib height and higher of the drawing force, the better of the anchor performance, but when the rib reach a certain height, drawing force will not increase obvious with the continue increase of rib height. Drawing force will different if the rib spacing is different, and with the increase of rib spacing, drawing force will increase at first and then reduce. When the rib spacing is about 30mm, the drawing force will get the maximum and the best of the anchor performance.

• Periodical: Applied Mechanics and Materials (Volumes 670-671)
• Pages: 1050-1054
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.670-671.1050
• Online since: October 2014
• Authors: Shuo Ren*, Jian Xing Wu, Jian Zhong Li
• Keywords: Anchor Performance, Bolt Shape, Drawing Force, Rib Height, Rib Spacing

References

[1] Kang Hongpu, Wang Jinhua. Rock bolting theory ang complete technology for coal roadways[M]. Beijing: China coal industry publishing house, 2007: 256-257.

[2] the Deep Mined Coal Industry Advisory Committee. Guidance on the use of rockbolts to support roadways in coal mines[M/OL]. Health and Safety Executive, 1996: 3-7. http：/ www. hse. gov. uk/pubns/mines02. Pdf.

[3] LIN Jian, KANG Hongpu. Research status-quo and tendency of thread-steel resin anchored bolt[J]. Coal Mining Technology, 2009(4): 1-4.

[4] Hou Chaojiong, Guo Lisheng, Gou Panfeng. Coal roadway bolting[M]. Xuzhou: China university of mining and technology press, (1999).

[5] Wang Yunfang, Wang Anguo, Qin Hongfei, et al. Rebar anchor design[J]. Coal, 2001(6): 26-27.

[6] YAO Jianwei . Development of dextrorotation hot-rolling mine resin anchor steel bars[J]. Shandong Metallurgy, 2009(3): 15-16.

[7] Wu Mingan, Zhao Wanshun, Huangfu Taiping. The development of hot rolled mining twisted bar[J]. Shanxi Metallurgy, 2002(2): 38-39.

[8] N Aziz, Jalalifar H, Concalves J. Bolt surface configurations and load transfer mechanism [C]. Proc. 7th underground Coal Operators Conference. Wollongong, 2006: 236-244.

[9] N Aziz. Bolt surface profiles- an important parameter in load transfer capacity appraisal[C]. Proceedings of The fifth International conference on ground control and mining construction, September, Perth, 2004: 221-230.

DOI: 10.1201/9780203023921-29

[10] N Aziz. A new technique to determine the load transfer capacity of resin anchored bolts[C]. 3rd Australian Coal Operators Conference, Wollongong, 2002：176-185.

[11] C. Chunlin L. Rock support design based on the concept of pressure arch[J]. International Journal of Rock Mechanics and Mining Sciences, 2006（43）: 1083-1090.

DOI: 10.1016/j.ijrmms.2006.02.007

[12] N Aziz, H Jalalifar, A Remennikov. Optimisation of the Bolt Profile Configuration for Load Transfer Enhancement[C]．Faculty of Engineering Coal Operators' Conference, 2008: 125-131.

[13] YANG Chao, LU Shi-liang, JIANG Yiao-dong. Controlling effects of support resistance on roadway deformation under different rock conditions[J]. Journal of China University of Mining & Technology, 2000, 29 (2): 170-173.
