Development and Application of Test Apparatus for Cutting Performance of Cutters of Large Excavation Equipment

Abstract:

In order to study the physical phenomena and mechanical properties of cutters when cutting rock, a test apparatus for cutting performance of cutters of large excavation equipment is established. The test apparatus is composed of a vertical loading system, a rotary loading system, a control system and a test system. Tests of different cut penetrations and spacings were carried out using the test apparatus. Meanwhile, the real-time images of the cutting process and forces acting on the cutters were obtained. The result shows that the test apparatus has good practicality and reliability, and it provides a laboratory test method to study the cutter-rock coupling mechanism and cutting performance of cutters.

• Periodical: Applied Mechanics and Materials (Volumes 670-671)
• Pages: 497-501
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.670-671.497
• Online since: October 2014
• Authors: Peng Lei Wang*, Yi Min Xia, Tao Ouyang, Lu Tang, Ben Guo
• Keywords: Cutting Mechanism, Mechanical Property, TBM, Test Apparatus

References

[1] Jingjian Zhang, Bingjun Fu: Advances in tunnel boring machine application in china, Chinese Journal of Rock Mechanics and Engineering, 2007, 26(2): 226-238. (In Chinese).

[2] Chun Liu. Development on Disc Cutter –Key Component of TBM [J]. China Railway Science, 2003, 24(4): 101-106. (In Chinese).

[3] O. Acaroglu, L. Ozdemir, B. Asbury. A fuzzy logic model to predict specific energy requirement for TBM performance prediction [J]. Tunnelling and Underground Space Technology, 2008, 23: 600-608.

DOI: 10.1016/j.tust.2007.11.003

[4] C. Balci, N. Bilgin. Correlative study of linear small and full-scale rock cutting tests to select mechanized excavation machines [J]. Rock Mechanics & Mining Sciences, 2007, 44: 468–476.

DOI: 10.1016/j.ijrmms.2006.09.001

[5] Jung-Woo Cho, Seokwon Jeon, Sang-Hwa Yu, et al. Optimum spacing of TBM disc cutters: A numerical simulation using the three-dimensional dynamic fracturing method [J]. Tunnelling and Underground Space Technology, 2010, 25: 230–244.

DOI: 10.1016/j.tust.2009.11.007

[6] Fujun Zhao, Xibing Li, Tao Feng. A new multifunctional testing device for rock fragmentation [J]. J. CENT. SOUTH UNIV. (SCIENCE AND TECHNOLOGY), 2004, 35(4): 651-656. (in Chinese).

[7] Qiwei Chen, Fengyuan Li, Weifeng Han. Development of Experimental System for Rock-breaking Mechanism of TBM Disc Cutters [J]. Tunnel Construction, 2013, 33(6): 437-442. (in Chinese).

[8] R. Gertsch, L. Gertsch, J. Rostami. Disc cutting tests in Colorado Red Granite: Implications for TBM performance prediction [J]. Rock Mechanics & Mining Sciences, 2007, 44: 238–246.

DOI: 10.1016/j.ijrmms.2006.07.007

[9] Z.X. Zhang, S.Q. Kou, X.C. Tan, et al. In-situ Measurements of Cutter Forces on Boring Machine at Äspö Hard Rock Laboratory Part I. Laboratory Calibration and In-situ Measurements [J]. Rock Mechanics and Rock Engineering, 2003, 36 (1): 39–61.

DOI: 10.1007/s00603-002-0036-y
