Comparison of Static and Dynamic Analysis on KJYF96/8 Mobile Refuge Chamber

Abstract:

This paper studied the difference between the static analysis and dynamic analysis on the mobile refuge chamber. The structure strength static analysis of KJYF96/8 mobile refuge chamber was made by the finite element software SolidWorks Simulation and the stress cloud chart and the displacement cloud chart were obtained. The corresponding relation between the dynamic analysis result and the static analysis result was obtained based on the comparison with the result of the dynamic analysis. The results indicate that the values of the max stress and displacement by static analysis with a uniform external pressure of the dynamic pressure peak value are greater than those by dynamic analysis. And the weighting method of static analysis can be used in the coal mine mobile refuge chamber structure design process instead of dynamic analysis.

• Periodical: Applied Mechanics and Materials (Volumes 670-671)
• Pages: 892-895
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.670-671.892
• Online since: October 2014
• Authors: An Ning Zhang*, Yu Ming Gu
• Keywords: Comparison, Dynamic Analysis, Refuge Chamber, Static Analysis

References

[1] XU Huang. Research on Emergency Rescue System of Coal Mine Mobile Refuge Chambers [D]. Beijing: University of Science and Technology Beijing, 2007. (In Chinese).

[2] GAO Guang-wei, ZHANG Lu-hua. Design principles of movable coal mine refuge chamber [J]. Journal of Safety Science and Technology, Vol. 5(2009) No. 4, pp.162-164. (In Chinese).

[3] The Anti Gas and Coal Dust Explosion Impact Finite Element Analysis Report of KJYF96/8 Coal Mine Mobile Refuge Chamber [R]. The State Key Laboratory of the Explosion of Science and Technology, 2011. (In Chinese).
