Finite Element Analysis for Petiole’s Fracture of Mine-Used Explosion-Proof Axial Fan

Abstract:

The petiole’s fracture of mine-used explosion-proof axial fan has been analyzed by means of finite element analysis (FEA). The reasons of the petiole’s fracture have been found through the structural static and modal simulation calculates for the axial fan’s impeller mechanical system. The structural static analysis results show that the petiole has stress concentration problems, and the modal analysis results demonstrate that the 6th-order natural frequency of the impeller system (which is 83.258 Hz) is close to 5 times of the impeller’s rotation frequency (which is 16.667*5 = 83.335 Hz), therefore it has high risk of resonance for the impeller system. So we conclude that the petiole’s fracture may greatly caused by the stress concentration and the risk of resonance, which may cause the fatigue cracks produced, and the cracks may gradually expanded and eventually caused the petiole fractured. At last, two measures to prevent the fracture of petioles were proposed.

• Periodical: Applied Mechanics and Materials (Volume 680)
• Pages: 228-232
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.680.228
• Online since: October 2014
• Authors: Zhi Liang Song, Da Cheng Xie*, Ling Yu Ou-Yang
• Keywords: Axial Fan, FEA, Modal Analysis, Petiole, Structural Static Analysis

References

[1] Wang Z, Wu H, Jia H, Vibration Characteristic FEM Analysis of High Aspect Ratio Fan Blades, J. Modeling Simulation, Vol. 7(2009) 387-392.

[2] CHEN Minsheng, Analysis on the High-Hrequency Vibration Characteristics of Static and Dynamic Adjustable Axial Fan, J. Electric Power, Vol. 46(2013) 119-123.

[3] Kai Zhang, Vibration Analysis of an Aero-Engine Compressor Blade, J. Mechanical Engineering and Material Science, V232. 4(2012) 63-64.

[4] Aw KC, Huang WDJ, De Silva MWRP, Evaluation of climatic vibration testing on plastic waterproof enclosure for electronic equipment using ANSYS (R) workbench, J. Mater Design, Vol. 28 (2007) 2505-2510.

DOI: 10.1016/j.matdes.2006.09.013

[5] Nishioka T, Kanno T, Hayami H, Characteristics of end-wall flow at spike and modal stall inceptions in a variable-pitch axial-flow fan, J. Proceedings of the ASME Turbo Expo, Vol. 6(2007) 307-318.

DOI: 10.1115/gt2007-27738

[6] Ai XF, Ba XQ, Wang B, Modal Analysis of Engine Bracket of 4G1 Based on ANSYS Workbench , J. Communications Standardization, Vol. 9(2008) 225-228.
