Comparative Analysis of Bearing Capacity of Inclined and Vertical Excavated Foundation

Abstract:

Excavated foundation has widely used in the field of transmission line engineering because of its large capacity to resist uplift and moment force. Elastic-plastic numerical model were established by using the finite element software ABAQUS focusing on the difference of bearing characteristics of inclined and vertical excavated foundation. There is very slight difference of axial uplift resistances between the both foundations because almost the same soil mass are mobilized at the same displacement loading. However, failure modes and horizontal resistances of negative, positive and vertical foundations are very different. The larger soil mass along the shaft of negative foundation is mobilized than positive and vertical foundations. The uplift resistances of vertical and negative foundations are about 5% and 25% higher than positive foundation at horizontal displacement of 50mm respectively.

You might also be interested in these eBooks

Materials Science, Mechanical Structures and Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 680)

Pages:

241-244

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.680.241

Citation:

Cite this paper

Online since:

October 2014

Authors:

Rong Chen, He Feng Liu, Dong Xue Hao*, Zhi Yun Wang

Keywords:

Bearing Capacity, Excavated Foundation, Failure Mode

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Li Yongxiang, Zhang Xi. Testing Study on Excavated Column Foundation for Towers of 750 kV Transmission Line in Northwest Gobi Gravel Area. Electric Power Construction, 2010, 31(9): 22~25.

Google Scholar

[2] Lu Xianlong. Field Test Analysis on Belled Pier Foundations under Tensile Load in Gravel Gobi. Journal of Civil, Architectural & Environmental Engineering, 2012, 34(4): 24～31.

Google Scholar

[3] Cui Qiang, Lu Xianlong. The Bearing Capacity Character of Dug Foundation with Plates under Horizontal Loads. Chinese Journal of Underground Space and Engineering, 2011, 7(3): 454~463.

Google Scholar

[4] Wang Yunhua, Ding Shijun, Liu Zhichao etc. Design and Application of Dredged Foundation for Transmission Tower in Xinjiang Gobi Area. Xinjiang Power Design Institute, 2012, 33(12): 17～22.

Google Scholar

[5] Yang Jian, Gao Yufeng. Characteristic of Digging Foundations of Transmission Lines under Inclined Loading. Industrial Construction, 2008, 38(6): 62～66.

Google Scholar

[6] Yang Jian, Gao Yu-feng, Cheng Yong-feng, et al. Behavior of inclined excavated foundation of transmission lines under lateral loading. Advances in Science and Technology of Water Resources, 2008, 28(4): 55-59.

Google Scholar
