Preliminary Numerical Analysis of a Platform Structure

Abstract:

Finite element analysis (FEA) has become an increasingly important tool in evaluating structural performance of platforms. This includes the use of this tool to perform strength, stability checks, optimisation of structural design upon subjected to design loads as well as to perform failure investigation of platforms upon subjected to special loading conditions such as impacts. Traditionally, small and medium enterprises utilises laboratory (physical) testing and heuristic experience to fabricate and test the platforms, nonetheless this approach is deemed too time consuming and cost demanding. Therefore, this study aims at reconstructing the actual design based on engineering drawings as well as performing stress analysis by means of a commercial FEA software package, ANSYS v14.0 by investigating the effects of two distinct loading impacts on a mild steel platform. The maximum stress and maximum displacement values obtained via the FEA simulation was then compared with values obtained via theoretical computation. The results obtained via the FEA simulation was found to be in good agreement with the exact solution. The present study is non-trivial as it contributes towards the knowledge in the design and optimisation of complex steel structures.

• Periodical: Applied Mechanics and Materials (Volume 680)
• Pages: 280-283
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.680.280
• Online since: October 2014
• Authors: Asrul Khairi Sohaimi*, Anwar P.P. Abdul Majeed, Jamaluddin Mahmud
• Keywords: Engineering Design, Finite Element Analysis (FEA), Platform Structure, Stress Analysis

References

[1] A. R Rahman, M. N. Tamin, and O. Kurdi, Stress analysis of heavy duty truck chassis as a preliminary data for its fatigue life prediction using FEM. Journal Mekanikal , (2008) 76-85.

[2] V. Adams, A. Askenazi, Building Better Products With Finite Element Analysis, Ward Press, Santa Fe, (1999).

[3] MRM Sahri, CMKIC Muhamad, MJAbd Latif and J Mahmud. Parametric Study of Low Velocity Impact using Finite Element Analysis. Applied Mechanics and Materials, 393 (2013) 397-402.

DOI: 10.4028/www.scientific.net/amm.393.397

[4] O. C Zienkiewicz, R. L Taylor, The Finite Element Method, Solid Mechanics, fifth ed., Butterworth Heinemann, Oxford, (2000).

[5] MAM Nor, H Rashid, WMFW Mahyuddin, MAM Azlan and J Mahmud. Stress Analysis of Low Loader Chassis. Procedia Engineering, Elsevier, 41 (2012) 995 – 1001.

DOI: 10.1016/j.proeng.2012.07.274

[6] MR Mahbob, J Mahmud, MAM Azlan, A Jumahat, Finite Element Analysis of Telecommunication Mini Mast Structure, Procedia Engineering, Elsevier, 68 (2013 ) 258 – 264.

DOI: 10.1016/j.proeng.2013.12.177

[7] Abdel Raheem, Shehata E., Abdel Aal, and M. A. Elsayed. Finite element analysis for structural performance of offshore platforms under environmental loads., Key Engineering Materials, 569 (2013)159-166.

DOI: 10.4028/www.scientific.net/kem.569-570.159
