Finite Element Analysis and Lightweight Design of Crusher Flywheel

Abstract:

Traditional jaw crusher has the problems of unreasonable structure, heavy weight, low utilization of material and high cost. This paper chooses the flywheel which has great influence on the total weight as the research object. Finite element method are used to anlysis stress and displacement distribution under the action of maximum crushing force. It shows weak link and surplus position of primary structure. Use the parametric design language APDL to establish and analyze finite element model, based on crusher structural features. Make lightweight design meeting the demands of intensity, stiffness and moment of inertia. The result indicates that modified flywheel is less than the original one by 5%, makes structure more reasonable and stress distribution more even.

• Periodical: Applied Mechanics and Materials (Volume 684)
• Pages: 297-302
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.684.297
• Online since: October 2014
• Authors: Chun Lan Yang*, Da Ming Huang, Fa Long Cheng
• Keywords: Crusher, Finite Element Analysis (FEA), Flywheel, Lightweight Design
